TM310 JCB TM310 Specifications & Technical Data (2005—2011)

The JCB TM310 is a wheel loader manufactured from 2005 to 2011. It has a weight of 8 tons and a transport length of 6.322 meters. …

The JCB TM310 is a wheel loader manufactured from 2005 to 2011. It has a weight of 8 tons and a transport length of 6.322 meters. The bucket capacity is 1 cubic meter, and the maximum discharge height is 4.511 meters. It has a travel speed of 40 km/h and a transport width of 2.35 meters. The transport height is 2.703 meters, and the turning radius outside is 4.633 meters.

Wheel Loaders JCB TM310

Visit JCB live at

Technical specs - TM310 JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8 t
Standard tyres
460/70 R24
Bucket capacity
1 m³
Transport length
6.322 m
Transport width
2.35 m
Transport height
2.703 m
Travel speed
40 km/h
Max. discharge height
4.511 m
Turning radius outside
4.633 m
Engine manuf.
JCB
Engine type
DieselMax
Engine power
97 kW
Displacement
4.4 l
Revolutions at max torque
1500 rpm
Max. torque
532 Nm
No. of cylinders
4
Cylinder bore x stroke
103x132 mm

More technical details, like: bucket width, bucket capacity min., bucket capacity max., steering mode, lifting force, model series, dimension lxwxh, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

JCB TM310 FAQ

When was the JCB TM310 manufactured?

The JCB TM310 was manufactured from 2005 to 2011.

How much does the JCB TM310 wheel loader weigh?

The JCB TM310 wheel loader weighs 8 tons.

What are the transport dimensions of the JCB TM310 wheel loader?

The JCB TM310 has a transport length of 6.32 meters, a transport width of 2.35 meters, and a transport height of 2.7 meters.

What is the travel speed of the JCB TM310 wheel loader?

The JCB TM310 has a travel speed of 40 km/h.

What is the standard tyre size of the JCB TM310 wheel loader?

The JCB TM310 wheel loader has standard tyres sized 460/70 R24.

What is the turning radius of the JCB TM310 wheel loader?

The JCB TM310 has an outside turning radius of 4.633 meters.

What is the maximum discharge height of the JCB TM310?

The JCB TM310 has a maximum discharge height of 4.51 meters.

What is the bucket capacity of the JCB TM310 wheel loader?

The JCB TM310 wheel loader has a bucket capacity of 1 cubic meter.

How much is a JCB TM310 Wheel loader (2005u20132011) worth?

The residual value of the JCB TM310 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

JCB TM310 overview

Hydraulic system

Boom and Carriage

Boom is manufactured from high tensile steel. Low maintenance, hard wearing pads. One boom end hydraulic service fitted as standard. Safety check valves fitted to carriage tilt; telescopic and boom lift rams. JCB Adaptive Load Control fitted in compliance with EN1500.


Bucket and Ground Engaging Tools

Versatility and Design

Incredible versatility is achieved through compact dimensions and the additional lift height provided by a telescopic boom. The manoeuvrability of articulated steering together with the side-shift function for easy load placing ability gives real spot loading precision. A spacious cab environment with intuitive controls makes operation simple even for the novice operator. Daily maintenance can be carried out simply and safely from ground level. Designed and manufactured to last, only the finest components are carefully selected to give durability and reliability.
