    JCB 457 HT Specifications & Technical Data (2019-2021)

    Rate this machine now!

    Weight: 20.94t – Standard tyres: 23.5 R25 XHA – Bucket capacity: 3.5m³ – Bucket capacity min.: 3.5m³ – Steering mode: KL – Transport length: 9.45m

    Total Cost of Ownership for 20t Wheel Loaders

    BUY (Annual Ownership Cost): 37 030.24 € RENTAL COST (Annual Rental Cost): 34 982.45 €.

    Customize the calculation *Presented prices are sample calculations.

    Provided by

    Technical specs - 457 HT JCB

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    Weight 20.94 t
    Standard tyres 23.5 R25 XHA
    Bucket capacity 3.5 m³
    Bucket capacity min. 3.5 m³
    Steering mode KL
    Transport length 9.45 m
    Transport width 2.7 m
    Transport height 3.43 m
    Travel speed 40 km/h
    Max. discharge height 4 m
    Turning radius outside 6.933 m
    Lifting force 145 kN
    Engine manuf. Cummins
    Engine type QSB6.7
    Engine power 210 kW
    Engine power 282 HP
    Displacement 6.7 l
    Revolutions at max torque 1300 rpm
    Max. torque 1350 Nm
    No. of cylinders 6
    Emission level V
    Bucket width ###
    Bucket capacity max. ###
    Dimension lxwxh ###
    Cylinder bore x stroke ###
    Weight ###

    Basic model with ROPS cabin, std. shovel and teeth

    457 HT JCB - Special equipment

    • Diesel particulate filter
    • Pivoting loader
    • telescopic
    • Aircondition
    • Quick hitch hydr.
    • Quick hitch mech.
