Technical specs - 437 HT JCB
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 15.52 t
- Standard tyres
- 20.5R25 XHA2
- Bucket capacity
- 2.3 m³
- Bucket capacity min.
- 2.3 m³
- Bucket capacity max.
- 2.7 m³
- Steering mode
- KL
- Transport length
- 8.49 m
- Transport width
- 2.6 m
- Transport height
- 3.36 m
- Travel speed
- 40 km/h
- Max. discharge height
- 3.45 m
- Turning radius outside
- 6.626 m
- Lifting force
- 147 kN
- Engine manuf.
- Cummins
- Engine type
- QSB6.7
- Engine power
- 136 kW
- Displacement
- 6.7 l
- Revolutions at max torque
- 1950 rpm
- Max. torque
- 840/1500 Nm
- No. of cylinders
- 6
- Cylinder bore x stroke
- 107x124 mm
- Emission level
- IV
More technical details, like: bucket width, model series, dimension lxwxh are available in the full technical specs.
Basic model with ROPS cabin, std. shovel and teeth
Special equipment
- Diesel particulate filter
-
No
- Swing loader
-
No
- telescopic
-
No
- Aircondition
-
Yes
- Quick hitch hydr.
-
Yes
- Quick hitch mech.
-
No
