437 Agri JCB 437 Agri Specifications & Technical Data (2019—2026)

The JCB 437 Agri is a wheel loader manufactured by JCB since 2019. It has a weight of 15.88 tons and a transport length of 7.93 me…

The JCB 437 Agri is a wheel loader manufactured by JCB since 2019. It has a weight of 15.88 tons and a transport length of 7.93 meters. The bucket capacity is 2.3 cubic meters, with a maximum discharge height of 3.45 meters. It has a travel speed of 40 km/h and a transport width of 2.6 meters. The transport height is 3.36 meters. The lifting force of this machine is 147 kN, and it has a turning radius outside of 6.286 meters. The bucket capacity ranges from a minimum of 2.3 cubic meters to a maximum of 2.7 cubic meters. It is equipped with special features such as air conditioning, a diesel particulate filter, and a quick hitch hydraulic system.

Wheel Loaders JCB 437 Agri
Wheel Loaders JCB 437 Agri
Wheel Loaders JCB 437 Agri
Wheel Loaders JCB 437 Agri
Wheel Loaders JCB 437 Agri
Wheel Loaders JCB 437 Agri

Visit JCB live at

Technical specs - 437 Agri JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
15.88 t
Standard tyres
750/65 R26
Bucket capacity
2.3 m³
Bucket capacity min.
2.3 m³
Bucket capacity max.
2.7 m³
Steering mode
KL
Transport length
7.93 m
Transport width
2.6 m
Transport height
3.36 m
Travel speed
40 km/h
Max. discharge height
3.45 m
Turning radius outside
6.286 m
Lifting force
147 kN
Model series
400
Engine manuf.
Cummins
Engine type
QSB6.7
Engine power
145 kW
Displacement
6.7 l
Revolutions at max torque
1300 rpm
Max. torque
881 Nm
No. of cylinders
6
Emission level
V

More technical details, like: bucket width, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
Yes
Swing loader
No
telescopic
No
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

JCB 437 Agri FAQ

When was the JCB 437 Agri manufactured?

The JCB 437 Agri was first produced in 2019.

How much does the JCB 437 Agri wheel loader weigh?

The JCB 437 Agri wheel loader weighs 15.88 tons.

What are the transport dimensions of the JCB 437 Agri wheel loader?

The JCB 437 Agri has a transport length of 7.93 meters, a transport width of 2.6 meters, and a transport height of 3.36 meters.

What is the travel speed of the JCB 437 Agri wheel loader?

The JCB 437 Agri has a travel speed of 40 km/h.

What are the standard tyre specifications of the JCB 437 Agri wheel loader?

The JCB 437 Agri wheel loader is equipped with standard tyres sized 750/65 R26.

What are the maneuverability specifications of the JCB 437 Agri wheel loader?

The JCB 437 Agri wheel loader has an articulated-frame steering system and an outside turning radius of 6.286 meters.

What is the power rating of the JCB 437 Agri wheel loader?

The source data does not provide power rating information for the JCB 437 Agri wheel loader.

What is the maximum discharge height of the JCB 437 Agri wheel loader?

The JCB 437 Agri wheel loader has a maximum discharge height of 3.45 meters.

What are the bucket capacity specifications of the JCB 437 Agri wheel loader?

The JCB 437 Agri wheel loader has a bucket capacity ranging from 2.3 mu00b3 to a maximum of 2.7 mu00b3, with a standard bucket capacity of 2.3 mu00b3.

How much is a JCB 437 Agri Wheel loader (2019u20132025) worth?

The residual value of the JCB 437 Agri depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
