426 e HT JCB 426 e HT Specifications & Technical Data (2007—2013)

The JCB 426 e HT is a wheel loader manufactured by JCB from 2007 to 2013. It has a weight of 12.7 tons and a transport length of 6…

The JCB 426 e HT is a wheel loader manufactured by JCB from 2007 to 2013. It has a weight of 12.7 tons and a transport length of 6.8 meters. The bucket capacity is 2 cubic meters with a width of 2.55 meters. The maximum discharge height is 5.095 meters. It has a travel speed of 40 km/h and a transport width of 2.482 meters. The transport height is 3.34 meters. The lifting force is 138 kN and the turning radius outside is 5.79 meters. It is equipped with air conditioning.

426 e HT

Years of manufacture: 2007—2013

Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 426 e HT JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 12.7 t

Standard tyres: 20.5-25 SGG

Bucket width: 2.55 m

Bucket capacity: 2 m³

Bucket capacity min.: 2 m³

Steering mode: KL

Transport length: 6.8 m

Transport width: 2.482 m

Transport height: 3.34 m

Travel speed: 40 km/h

Max. discharge height: 5.095 m

Turning radius outside: 5.79 m

Lifting force: 138 kN

Engine manuf.: Cummins

Engine type: QSB6.7

Engine power: 125 kW

Displacement: 6.7 l

Revolutions at max torque: 2000 rpm

More technical details, like: bucket capacity max., model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

JCB 426 e HT FAQ

When was the JCB 426 e HT manufactured?

The JCB 426 e HT was manufactured from 2007 to 2013.

How much does the JCB 426 e HT wheel loader weigh?

The JCB 426 e HT wheel loader weighs 12.7 tons.

What are the transport dimensions of the JCB 426 e HT wheel loader?

The JCB 426 e HT has a transport length of 6.8 meters, a transport width of 2.48 meters, and a transport height of 3.34 meters.

What is the travel speed of the JCB 426 e HT wheel loader?

The JCB 426 e HT wheel loader has a travel speed of 40 km/h.

What are the standard tyre specifications of the JCB 426 e HT?

The JCB 426 e HT wheel loader is equipped with standard tyres sized 20.5-25 SGG.

What are the maneuverability specifications of the JCB 426 e HT wheel loader?

The JCB 426 e HT wheel loader has an articulated-frame steering system and an outside turning radius of 5.79 meters.

What is the lifting force of the JCB 426 e HT wheel loader?

The JCB 426 e HT wheel loader has a lifting force of 138 kN.

What is the maximum discharge height of the JCB 426 e HT wheel loader?

The JCB 426 e HT has a maximum discharge height of 5.1 meters.

What are the bucket specifications of the JCB 426 e HT wheel loader?

The JCB 426 e HT has a bucket capacity of 2 cubic meters, a minimum bucket capacity of 2 cubic meters, and a bucket width of 2.55 meters.
