JCB 417 HT Specifications & Technical Data (2016-2021)

Name: JCB 417 HT Wheel Loaders
Brand: JCB

The JCB 417 HT is a wheel loader manufactured by JCB from 2016 to 2021. It has a weight of 10.06 tons and a transport length of 7.…

The JCB 417 HT is a wheel loader manufactured by JCB from 2016 to 2021. It has a weight of 10.06 tons and a transport length of 7.14 meters. The bucket capacity is 1.6 cubic meters with a width of 2.4 meters. The maximum discharge height is 3.52 meters and it has a travel speed of 40 km/h. The transport width is 2.33 meters and the transport height is 3.08 meters. It has a lifting force of 65 kN and a turning radius outside of 5.35 meters. The minimum bucket capacity is 1.4 cubic meters. It is equipped with air conditioning and a quick hitch hydraulic system.

417 HT

Years of manufacture: 2016—2021

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events & News

Technical specs - 417 HT JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 10.06 t

Standard tyres: 15.5 R25 XHA

Bucket width: 2.4 m

Bucket capacity: 1.6 m³

Bucket capacity min.: 1.4 m³

Steering mode: KL

Transport length: 7.14 m

Transport width: 2.33 m

Transport height: 3.08 m

Travel speed: 40 km/h

Max. discharge height: 3.52 m

Turning radius outside: 5.35 m

Lifting force: 65 kN

Engine manuf.: JCB

Engine type: EcoMax

Engine power: 93 kW

Displacement: 5.193 l

Emission level: IV

More technical details, like: bucket capacity max., model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: Yes
Quick hitch mech.: No
