JCB 417 HT Specifications & Technical Data (2016-2021)

Name: JCB 417 HT Wheel Loaders
Brand: JCB

The JCB 417 HT is a wheel loader manufactured by JCB from 2016 to 2021. It has a weight of 9.77 tons and a transport length of 6.4…

The JCB 417 HT is a wheel loader manufactured by JCB from 2016 to 2021. It has a weight of 9.77 tons and a transport length of 6.49 meters. The bucket capacity is 1.6 cubic meters with a width of 2.4 meters. The maximum discharge height is 2.88 meters. It has a travel speed of 40 km/h and a transport width of 2.33 meters. The transport height is 3.08 meters. The lifting force is 65 kN and the turning radius outside is 5.35 meters. The bucket capacity minimum is 1.4 cubic meters. It is equipped with air conditioning and a quick hitch hydraulic system.

417 HT

Years of manufacture: 2016—2021

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events & News

Technical specs - 417 HT JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 9.77 t

Standard tyres: 15.5 R25 XHA

Bucket width: 2.4 m

Bucket capacity: 1.6 m³

Bucket capacity min.: 1.4 m³

Steering mode: KL

Transport length: 6.49 m

Transport width: 2.33 m

Transport height: 3.08 m

Travel speed: 40 km/h

Max. discharge height: 2.88 m

Turning radius outside: 5.35 m

Lifting force: 65 kN

Engine manuf.: JCB

Engine type: EcoMax

Engine power: 93 kW

Displacement: 5.193 l

Emission level: IV

More technical details, like: bucket capacity max., model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: Yes
Quick hitch mech.: No
