411 HT JCB 411 HT Specifications & Technical Data (2001—2008)

Model rating
8,00 / 10

The JCB 411 HT is a wheel loader manufactured by JCB from 2001 to 2008. It has a weight of 7.66 tons and a transport length of 5.9…

The JCB 411 HT is a wheel loader manufactured by JCB from 2001 to 2008. It has a weight of 7.66 tons and a transport length of 5.95 meters. The bucket capacity is 1.4 cubic meters, with a maximum discharge height of 2.7 meters. The travel speed of the machine is 37.5 km/h. It has a transport width of 2.25 meters and a transport height of 3.13 meters. The turning radius outside is 5.41 meters. The machine is equipped with a quick hitch mechanism.

Wheel Loaders JCB 411 HT
Wheel Loaders JCB 411 HT
Wheel Loaders JCB 411 HT
Wheel Loaders JCB 411 HT

Visit JCB live at

Technical specs - 411 HT JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
7.66 t
Standard tyres
15.5 R25
Bucket capacity
1.4 m³
Bucket capacity min.
1.4 m³
Steering mode
KL
Transport length
5.95 m
Transport width
2.25 m
Transport height
3.13 m
Travel speed
37.5 km/h
Max. discharge height
2.7 m
Turning radius outside
5.41 m
Engine manuf.
Perkins
Engine type
1004.4LR2
Engine power
60 kW

More technical details, like: bucket width, bucket capacity max., lifting force, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
Yes

Download datasheets (PDF)

JCB 411 HT FAQ

When was the JCB 411 HT manufactured?

The JCB 411 HT was manufactured from 2001 to 2008.

How much does the JCB 411 HT wheel loader weigh?

The JCB 411 HT wheel loader weighs 7.66 tons.

What are the transport dimensions of the JCB 411 HT wheel loader?

The JCB 411 HT has a transport length of 5.95 meters, a transport width of 2.25 meters, and a transport height of 3.13 meters.

What is the travel speed of the JCB 411 HT wheel loader?

The JCB 411 HT wheel loader has a travel speed of 37.5 km/h.

What is the standard tyre size of the JCB 411 HT wheel loader?

The JCB 411 HT wheel loader is equipped with standard tyres sized 15.5 R25.

What are the maneuverability specifications of the JCB 411 HT wheel loader?

The JCB 411 HT wheel loader has an articulated-frame steering system and an outside turning radius of 5.41 meters.

What is the maximum discharge height of the JCB 411 HT wheel loader?

The JCB 411 HT wheel loader has a maximum discharge height of 2.7 meters.

What is the bucket capacity of the JCB 411 HT wheel loader?

The JCB 411 HT wheel loader has a bucket capacity of 1.4 cubic meters.

How much is a JCB 411 HT Wheel loader (2001u20132008) worth?

The residual value of the JCB 411 HT depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
