Technical specs - HL975 Hyundai
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 26.5 t
- Standard tyres
- 26.5 R 25
- Bucket width
- 3.25 m
- Bucket capacity
- 4.8 m³
- Bucket capacity min.
- 4.6 m³
- Bucket capacity max.
- 5.2 m³
- Steering mode
- KL
- Transport length
- 9.205 m
- Transport width
- 2.975 m
- Transport height
- 3.59 m
- Travel speed
- 40 km/h
- Max. discharge height
- 4.425 m
- Turning radius outside
- 6.523 m
- Engine manuf.
- Cummins
- Engine type
- X12
- Engine power
- 250 kW
- Displacement
- 11.8 l
- Revolutions at max torque
- 1400 rpm
- Max. torque
- 1765 Nm
- No. of cylinders
- 6
- Cylinder bore x stroke
- 132x144 mm
- Emission level
- V
Basic model with ROPS cabin, std. shovel and teeth
Special equipment
- Diesel particulate filter
-
Yes
- Swing loader
-
No
- telescopic
-
No
- Aircondition
-
Yes
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
No
Download datasheets (PDF)
