ZW 75 Hitachi ZW 75 Specifications & Technical Data (2010—2015)

The Hitachi ZW 75 is a wheel loader manufactured by Hitachi from 2010 to 2015. It has a weight of 5.34 tons and a transport length…

The Hitachi ZW 75 is a wheel loader manufactured by Hitachi from 2010 to 2015. It has a weight of 5.34 tons and a transport length of 5.36 meters. The bucket capacity is 0.7 cubic meters with a bucket width of 1.8 meters. The maximum discharge height is 2.5 meters and it has a travel speed of 20 km/h. The transport width is 1.76 meters and the transport height is 2.49 meters. The lifting force is 42.3 kN and the turning radius outside is 4.185 meters. The machine is equipped with a quick hitch mechanism. The maximum bucket capacity is 1 cubic meter and the minimum bucket capacity is 0.7 cubic meters.

Visit Hitachi live at

ZW 75

Years of manufacture: 2010—2015

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - ZW 75 Hitachi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.34 t

Standard tyres: 365/70 R18

Bucket width: 1.8 m

Bucket capacity: 0.7 m³

Bucket capacity min.: 0.7 m³

Bucket capacity max.: 1 m³

Steering mode: KL

Transport length: 5.36 m

Transport width: 1.76 m

Transport height: 2.49 m

Travel speed: 20 km/h

Max. discharge height: 2.5 m

Turning radius outside: 4.185 m

Lifting force: 42.3 kN

Model series: ZW

Engine manuf.: Kubota

Engine type: V3307DI-T

Engine power: 45.6 kW

Displacement: 3.331 l

More technical details, like: dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: Yes

Download datasheets (PDF)

Hitachi ZW 75 FAQ

When was the Hitachi ZW 75 manufactured?

The Hitachi ZW 75 was manufactured from 2010 to 2015.

How much does the Hitachi ZW 75 wheel loader weigh?

The Hitachi ZW 75 wheel loader weighs 5.34 tons.

What are the transport dimensions of the Hitachi ZW 75 wheel loader?

The Hitachi ZW 75 has a transport length of 5.36 meters, a transport width of 1.76 meters, and a transport height of 2.49 meters.

What is the travel speed of the Hitachi ZW 75 wheel loader?

The Hitachi ZW 75 wheel loader has a travel speed of 20 km/h.

What is the standard tyre size of the Hitachi ZW 75 wheel loader?

The Hitachi ZW 75 wheel loader has standard tyres sized 365/70 R18.

What are the maneuverability specifications of the Hitachi ZW 75 wheel loader?

The Hitachi ZW 75 wheel loader has an articulated-frame steering mode and an outside turning radius of 4.185 meters.

What is the lifting force of the Hitachi ZW 75 wheel loader?

The Hitachi ZW 75 wheel loader has a lifting force of 42.3 kN.

What is the maximum discharge height of the Hitachi ZW 75?

The Hitachi ZW 75 has a maximum discharge height of 2.5 meters.

What are the specifications of the bucket on the Hitachi ZW 75 wheel loader?

The Hitachi ZW 75 wheel loader has a bucket with a capacity ranging from 0.7 to 1 cubic meter and a bucket width of 1.8 meters.
