LX 40 Hitachi LX 40 Specifications & Technical Data (2002—2026)

The Hitachi LX 40 is a wheel loader manufactured since 2002. It has a weight of 3.74 tons and a transport length of 4.695 meters. …

The Hitachi LX 40 is a wheel loader manufactured since 2002. It has a weight of 3.74 tons and a transport length of 4.695 meters. The bucket capacity is 0.7 cubic meters with a width of 1.69 meters. The maximum discharge height is 3.14 meters. It has a travel speed of 15 km/h and a transport width of 1.655 meters. The transport height is 2.54 meters. The lifting force is 33.4 kN and the turning radius outside is 3.22 meters. It is equipped with air conditioning.

Wheel Loaders Hitachi LX 40
Wheel Loaders Hitachi LX 40
Wheel Loaders Hitachi LX 40
Wheel Loaders Hitachi LX 40

Visit Hitachi live at

Technical specs - LX 40 Hitachi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.74 t
Standard tyres
15.5/60-15-8PR (L2)
Bucket width
1.69 m
Bucket capacity
0.7 m³
Transport length
4.695 m
Transport width
1.655 m
Transport height
2.54 m
Travel speed
15 km/h
Max. discharge height
3.14 m
Turning radius outside
3.22 m
Lifting force
33.4 kN
Engine manuf.
Kubota
Engine type
D1503-DI-T-K2A
Engine power
27.2 kW
Displacement
1.499 l
Revolutions at max torque
2500 rpm

More technical details, like: bucket capacity min., bucket capacity max., steering mode, model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Hitachi LX 40 FAQ

When was the Hitachi LX 40 manufactured?

The Hitachi LX 40 was first produced in 2002.

How much does the Hitachi LX 40 wheel loader weigh?

The Hitachi LX 40 wheel loader weighs 3.74 tons.

What are the transport dimensions of the Hitachi LX 40 wheel loader?

The Hitachi LX 40 has a transport length of 4.7 meters, a transport width of 1.66 meters, and a transport height of 2.54 meters.

What is the travel speed of the Hitachi LX 40 wheel loader?

The Hitachi LX 40 wheel loader has a travel speed of 15 km/h.

What are the undercarriage tyre specifications of the Hitachi LX 40 wheel loader?

The Hitachi LX 40 wheel loader is equipped with standard tyres sized 15.5/60-15-8PR (L2).

What is the turning radius of the Hitachi LX 40 wheel loader?

The Hitachi LX 40 wheel loader has an outside turning radius of 3.22 meters.

What is the power rating of the Hitachi LX 40 wheel loader?

There is no power rating data available for the Hitachi LX 40 wheel loader in the provided source data.

What is the maximum discharge height of the Hitachi LX 40?

The Hitachi LX 40 has a maximum discharge height of 3.14 meters.

What are the specifications of the primary work tool bucket on the Hitachi LX 40?

The primary work tool bucket of the Hitachi LX 40 has a capacity of 0.7 cubic meters and a width of 1.69 meters.

How much is a Hitachi LX 40 Wheel loader (2002u20132025) worth?

The residual value of the Hitachi LX 40 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Hitachi LX 40 overview

Hitachi LX 40 features overview

Small Body. Big Performance.

The LX has power for tough job sites. The design has the operator comfort in mind. It is equipped with the new 2-mode HST system to boost productivity. This new model also offers enhanced safety features and ease of maintenance. It is environment friendly.


Safety

A sealed internal wet-disc brake system is used to provide sure braking, even on wet and muddy surfaces. This type of brake system also has low wear, so there is less maintenance.


Maintenance

The engine compartment can be easily opened and closed on both canopy and cab-equipped models. Plenty of access for efficient inspections and maintenance.


Engine / Powertrain / Drivetrain

Electric Parking Brake Switch

The parking brake is engaged automatically when the engine is turned off. The electric parking brake switch helps prevent travel with parking brake on.


Hydraulic system

Solenoid fuel feed pump

Equipped with an automatic air bleeder system. Simply turn the starter switch on to operate. Air is removed when the fuel is cut off, which also helps for easier restarting.


Bucket and Ground Engaging Tools

Agriculture bucket (For all models)

The higher capacity of this wide bucket makes it suitable for handling feed, fertilizer or cleaning livestock pens.
