G5000 Giant G5000 Specifications & Technical Data (2019—2026)

The Giant G5000 is a wheel loader manufactured since 2019. It has a weight of 5.2 tons and a transport length of 4.16 meters. The …

The Giant G5000 is a wheel loader manufactured since 2019. It has a weight of 5.2 tons and a transport length of 4.16 meters. The bucket width is 1.9 meters and the maximum discharge height is 2.55 meters. It has a travel speed of 20 km/h and a transport width of 1.46 meters. The transport height is 2.52 meters, and the turning radius outside is 3.19 meters. The lifting force is 33 kN, and the bucket capacity ranges from 0.81 to 0.86 cubic meters. Special equipment includes a diesel particulate filter and a quick hitch hydraulic mechanism.

G5000

Years of manufacture: 2019—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - G5000 Giant

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.2 t

Standard tyres: 11.5/80-15.3AS

Bucket width: 1.9 m

Bucket capacity min.: 0.81 m³

Bucket capacity max.: 0.86 m³

Steering mode: KL

Transport length: 4.16 m

Transport width: 1.46 m

Transport height: 2.52 m

Travel speed: 20 km/h

Max. discharge height: 2.55 m

Turning radius outside: 3.19 m

Lifting force: 33 kN

Model series: G

Engine manuf.: Kubota

Engine type: V3307-CR-TE

Engine power: 55 kW

No. of cylinders: 4

Emission level: V

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: Yes
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Giant G5000 FAQ

When was the Giant G5000 manufactured?

The Giant G5000 was first produced in 2019.

How much does the Giant G5000 wheel loader weigh?

The Giant G5000 wheel loader weighs 5.2 tons.

What are the transport dimensions of the Giant G5000 wheel loader?

The Giant G5000 has a transport length of 4.16 meters, a transport width of 1.46 meters, and a transport height of 2.52 meters.

What is the travel speed of the Giant G5000 wheel loader?

The Giant G5000 wheel loader has a travel speed of 20 km/h.

What are the standard tyres of the Giant G5000 wheel loader?

The Giant G5000 wheel loader is equipped with standard tyres sized 11.5/80-15.3AS.

What are the maneuverability specifications of the Giant G5000 wheel loader?

The Giant G5000 wheel loader has an articulated-frame steering system and an outside turning radius of 3.19 meters.

What is the lifting force of the Giant G5000 wheel loader?

The Giant G5000 wheel loader has a lifting force of 33 kN.

What is the maximum discharge height of the Giant G5000 wheel loader?

The Giant G5000 wheel loader has a maximum discharge height of 2.55 meters.

What are the specifications of the bucket on the Giant G5000 wheel loader?

The Giant G5000 wheel loader has a bucket with a maximum capacity of 0.86 cubic meters, a minimum capacity of 0.81 cubic meters, and a width of 1.9 meters.
