AL 240 Gehl AL 240 Specifications & Technical Data (2008—2016)

The Gehl AL 240 is a wheel loader manufactured by Gehl from 2008 to 2016. It has a weight of 2.17 tons and a transport length of 4…

The Gehl AL 240 is a wheel loader manufactured by Gehl from 2008 to 2016. It has a weight of 2.17 tons and a transport length of 4.04 meters. The bucket capacity is 0.26 cubic meters with a bucket width of 1.08 meters. The maximum discharge height is 2.04 meters and it has a travel speed of 13.5 km/h. The transport width is 1.06 meters and the transport height is 2.21 meters. The turning radius outside is 1.03 meters. The machine is equipped with a quick hitch mechanism.

AL 240

Years of manufacture: 2008—2016

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - AL 240 Gehl

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.17 t

Standard tyres: 27x10.50-15

Bucket width: 1.08 m

Bucket capacity: 0.26 m³

Bucket capacity min.: 0.26 m³

Steering mode: KL

Transport length: 4.04 m

Transport width: 1.06 m

Transport height: 2.21 m

Travel speed: 13.5 km/h

Max. discharge height: 2.04 m

Turning radius outside: 1.03 m

Model series: AL

Engine manuf.: Yanmar

Engine type: 3TNV88

Engine power: 26 kW

Displacement: 1.6 l

Max. torque: 102.7/1680 Nm

No. of cylinders: 3

Emission level: 3A

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: Yes

Download datasheets (PDF)

AL 240 Gehl Specification for Europe (DE)

Gehl AL 240 FAQ

When was the Gehl AL 240 manufactured?

The Gehl AL 240 was manufactured from 2008 to 2016.

How much does the Gehl AL 240 wheel loader weigh?

The Gehl AL 240 wheel loader weighs 2.17 tons.

What are the transport dimensions of the Gehl AL 240 wheel loader?

The Gehl AL 240 has a transport length of 4.04 meters, a transport width of 1.06 meters, and a transport height of 2.21 meters.

What is the travel speed of the Gehl AL 240 wheel loader?

The Gehl AL 240 wheel loader has a travel speed of 13.5 km/h.

What is the standard tyre size of the Gehl AL 240 wheel loader?

The Gehl AL 240 wheel loader has standard tyres sized 27x10.50-15.

What are the maneuverability specifications of the Gehl AL 240 wheel loader?

The Gehl AL 240 wheel loader has an articulated-frame steering system and an outside turning radius of 1.03 meters.

What is the maximum discharge height of the Gehl AL 240 wheel loader?

The Gehl AL 240 wheel loader has a maximum discharge height of 2.04 meters.

What are the specifications of the primary work tool bucket on the Gehl AL 240?

The Gehl AL 240 has a bucket with a capacity of 0.26 cubic meters, a minimum capacity of 0.26 cubic meters, and a width of 1.08 meters.
