Furukawa 345 Wheel Loader Specs & Dimensions (1990 - 1997)

Technical specs - 345 Furukawa

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 16.5 t

Standard tyres: 23.5-25

Bucket capacity: 3 m³

Bucket capacity min.: 3 m³

Steering mode: KL

Transport length: 7.7 m

Transport width: 2.85 m

Transport height: 3.4 m

Engine manuf.: Furukawa

Engine type: F 683 T

Engine power: 144 kW

More technical details, like: bucket width, bucket capacity max., travel speed, max. discharge height, turning radius outside, lifting force, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders...

More technical details, like: bucket width, bucket capacity max., travel speed, max. discharge height, turning radius outside, lifting force, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

345 Furukawa Specification for Europe (FR)

Furukawa 345 FAQ

When was the Furukawa 345 manufactured?

The Furukawa 345 was manufactured from 1990 to 1997.

How much does the Furukawa 345 wheel loader weigh?

The Furukawa 345 wheel loader weighs 16.5 tons.

What are the transport dimensions of the Furukawa 345 wheel loader?

The Furukawa 345 has a transport length of 7.7 meters, a transport width of 2.85 meters, and a transport height of 3.4 meters.

What are the undercarriage specifications of the Furukawa 345 wheel loader?

The Furukawa 345 wheel loader is equipped with standard tyres sized 23.5-25.

What is the steering mode of the Furukawa 345 wheel loader?

The Furukawa 345 wheel loader has articulated-frame steering.

What are the bucket capacity specifications of the Furukawa 345 wheel loader?

The Furukawa 345 wheel loader has a bucket capacity of 3 cubic meters, with a minimum bucket capacity of 3 cubic meters.

How much is a Furukawa 345 Wheel loader (1990u20131997) worth?

The residual value of the Furukawa 345 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
