Fiat Kobelco W 60 Wheel Loader Specs & Dimensions (2002 - 2005)

Technical specs - W 60 Fiat Kobelco

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.7 t

Standard tyres: 14.5-20

Bucket capacity: 0.8 m³

Bucket capacity min.: 0.8 m³

Steering mode: KL

Transport length: 5.32 m

Transport width: 2.05 m

Transport height: 2.79 m

Engine manuf.: Perkins

Engine type: 704.30 EI

Engine power: 42 kW

More technical details, like: bucket width, bucket capacity max., travel speed, max. discharge height, turning radius outside, lifting force, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders...

More technical details, like: bucket width, bucket capacity max., travel speed, max. discharge height, turning radius outside, lifting force, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: Yes

Download datasheets (PDF)

W 60 Fiat Kobelco Specification for Europe (DE)

Fiat Kobelco W 60 FAQ

When was the Fiat Kobelco W 60 manufactured?

The Fiat Kobelco W 60 was manufactured from 2002 to 2005.

How much does the Fiat Kobelco W 60 weigh?

The Fiat Kobelco W 60 weighs 4.7 tons.

What are the transport dimensions of the Fiat Kobelco W 60 wheel loader?

The Fiat Kobelco W 60 has a transport length of 5.32 meters, a transport width of 2.05 meters, and a transport height of 2.79 meters.

What are the undercarriage specifications of the Fiat Kobelco W 60 wheel loader?

The Fiat Kobelco W 60 wheel loader is equipped with standard tyres sized 14.5-20.

What is the steering mode of the Fiat Kobelco W 60 wheel loader?

The Fiat Kobelco W 60 wheel loader has articulated-frame steering.

What is the bucket capacity of the Fiat Kobelco W 60 wheel loader?

The bucket capacity of the Fiat Kobelco W 60 wheel loader is 0.8 cubic meters.

How much is a Fiat Kobelco W 60 Wheel loader (2002u20132005) worth?

The residual value of the Fiat Kobelco W 60 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
