W 230 Evolution Fiat Kobelco W 230 Evolution Specifications & Technical Data (2002—2005)

The Fiat Kobelco W 230 Evolution is a wheel loader manufactured from 2002 to 2005. It has a weight of 20.8 tons and a transport le…

The Fiat Kobelco W 230 Evolution is a wheel loader manufactured from 2002 to 2005. It has a weight of 20.8 tons and a transport length of 8.5 meters. The bucket capacity is 3.6 cubic meters, with a width of 3.065 meters. The maximum discharge height is 3.05 meters. It has a travel speed of 43.8 km/h and a transport width of 2.9 meters. The transport height is 3.5 meters. The lifting force is 182 kN. The turning radius outside is 6.7 meters. The bucket capacity ranges from a minimum of 3.6 cubic meters to a maximum of 4 cubic meters. It is equipped with air conditioning.

W 230 Evolution

Years of manufacture: 2002—2005

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - W 230 Evolution Fiat Kobelco

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 20.8 t

Standard tyres: 750/65 R 25

Bucket width: 3.065 m

Bucket capacity: 3.6 m³

Bucket capacity min.: 3.6 m³

Bucket capacity max.: 4 m³

Steering mode: KL

Transport length: 8.5 m

Transport width: 2.9 m

Transport height: 3.5 m

Travel speed: 43.8 km/h

Max. discharge height: 3.05 m

Turning radius outside: 6.7 m

Lifting force: 182 kN

Engine manuf.: Cummins

Engine type: 6CTAA

Engine power: 168 kW

Displacement: 8.3 l

Revolutions at max torque: 2200 rpm

More technical details, like: model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

W 230 Evolution Fiat Kobelco Specification for Europe (DE)

Fiat Kobelco W 230 Evolution FAQ

When was the Fiat Kobelco W 230 Evolution manufactured?

The Fiat Kobelco W 230 Evolution was manufactured from 2002 to 2005.

How much does the Fiat Kobelco W 230 Evolution weigh?

The Fiat Kobelco W 230 Evolution weighs 20.8 tons.

What are the transport dimensions of the Fiat Kobelco W 230 Evolution?

The Fiat Kobelco W 230 Evolution has a transport length of 8.5 meters, a transport width of 2.9 meters, and a transport height of 3.5 meters.

What is the travel speed of the Fiat Kobelco W 230 Evolution?

The Fiat Kobelco W 230 Evolution has a travel speed of 43.8 km/h.

What is the size of the standard tyres on the Fiat Kobelco W 230 Evolution?

The Fiat Kobelco W 230 Evolution has standard tyres sized 750/65 R 25.

What are the maneuverability specifications of the Fiat Kobelco W 230 Evolution wheel loader?

The Fiat Kobelco W 230 Evolution has an outside turning radius of 6.7 meters and features articulated-frame steering.

What is the lifting force rating of the Fiat Kobelco W 230 Evolution?

The Fiat Kobelco W 230 Evolution has a lifting force of 182 kN.

What is the maximum discharge height of the Fiat Kobelco W 230 Evolution?

The Fiat Kobelco W 230 Evolution has a maximum discharge height of 3.05 meters.

What are the bucket specifications of the Fiat Kobelco W 230 Evolution wheel loader?

The Fiat Kobelco W 230 Evolution has a bucket capacity ranging from 3.6 to 4 cubic meters, with a bucket width of 3.07 meters.
