DL250-5 Doosan DL250-5 Specifications & Technical Data (2016—2021)

The Doosan DL250-5 is a wheel loader manufactured from 2016 to 2021. It has a weight of 13.54 tons and a transport length of 7.58 …

The Doosan DL250-5 is a wheel loader manufactured from 2016 to 2021. It has a weight of 13.54 tons and a transport length of 7.58 meters. The bucket width is 2.74 meters and the maximum discharge height is 2.72 meters. It has a travel speed of 38 km/h and a transport width and height of 2.74 meters and 3.28 meters, respectively. The lifting force is 107 kN and the turning radius outside is 6.07 meters. The minimum bucket capacity is 2.5 cubic meters.

DL250-5

Years of manufacture: 2016—2021

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - DL250-5 Doosan

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 13.54 t

Standard tyres: 20.5 R 25

Bucket width: 2.74 m

Bucket capacity min.: 2.5 m³

Steering mode: KL

Transport length: 7.58 m

Transport width: 2.74 m

Transport height: 3.28 m

Travel speed: 38 km/h

Max. discharge height: 2.72 m

Turning radius outside: 6.07 m

Lifting force: 107 kN

Model series: DL

Engine manuf.: Doosan

Engine type: DL 06

Engine power: 128 kW

Displacement: 5.9 l

Revolutions at max torque: 1400 rpm

Max. torque: 804 Nm

No. of cylinders: 6

Cylinder bore x stroke: 100 x 125 mm

Emission level: Stage IV

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Doosan DL250-5 FAQ

When was the Doosan DL250-5 manufactured?

The Doosan DL250-5 was manufactured from 2016 to 2021.

How much does the Doosan DL250-5 weigh?

The Doosan DL250-5 weighs 13.54 tons.

What are the transport dimensions of the Doosan DL250-5 wheel loader?

The Doosan DL250-5 has a transport length of 7.58 meters, a transport width of 2.74 meters, and a transport height of 3.28 meters.

What is the travel speed of the Doosan DL250-5 wheel loader?

The Doosan DL250-5 has a travel speed of 38 km/h.

What are the undercarriage specifications of the Doosan DL250-5 wheel loader?

The Doosan DL250-5 wheel loader is equipped with standard tyres sized 20.5 R 25.

What are the maneuverability specifications of the Doosan DL250-5 wheel loader?

The Doosan DL250-5 has an outside turning radius of 6.07 meters and features articulated-frame steering.

What are the power ratings of the Doosan DL250-5 wheel loader?

There is no power rating information available for the Doosan DL250-5 wheel loader in the provided data.

What is the maximum discharge height of the Doosan DL250-5?

The Doosan DL250-5 has a maximum discharge height of 2.72 meters.

What are the specifications of the primary work tool (bucket) on the Doosan DL250-5?

The Doosan DL250-5 has a bucket with a minimum capacity of 2.5 cubic meters and a width of 2.74 meters.

How much is a Doosan DL250-5 Wheel loader (2016u20132021) worth?

The residual value of the Doosan DL250-5 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
