DL 300 Doosan DL 300 Specifications & Technical Data (2006—2013)

The Doosan DL 300 is a wheel loader manufactured by Doosan from 2006 to 2013. It has a weight of 18.1 tons and a transport length …

The Doosan DL 300 is a wheel loader manufactured by Doosan from 2006 to 2013. It has a weight of 18.1 tons and a transport length of 8.15 meters. The bucket capacity is 3 cubic meters with a width of 2.92 meters. The maximum discharge height is 2.9 meters. It has a travel speed of 34 km/h and a transport width of 2.92 meters. The transport height is 3.47 meters. The lifting force is 162 kN and the turning radius outside is 6.35 meters. The wheel loader is equipped with air conditioning.

DL 300

Years of manufacture: 2006—2013

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - DL 300 Doosan

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 18.1 t

Standard tyres: 23.5 %25 L3

Bucket width: 2.92 m

Bucket capacity: 3 m³

Bucket capacity min.: 3 m³

Steering mode: KL

Transport length: 8.15 m

Transport width: 2.92 m

Transport height: 3.47 m

Travel speed: 34 km/h

Max. discharge height: 2.9 m

Turning radius outside: 6.35 m

Lifting force: 162 kN

Model series: DL

Engine manuf.: Doosan

Engine type: DL 08

Engine power: 169 kW

Displacement: 7.6 l

Revolutions at max torque: 2000 rpm

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Doosan DL 300 FAQ

When was the Doosan DL 300 manufactured?

The Doosan DL 300 was manufactured from 2006 to 2013.

How much does the Doosan DL 300 wheel loader weigh?

The Doosan DL 300 wheel loader weighs 18.1 tons.

What are the transport dimensions of the Doosan DL 300 wheel loader?

The Doosan DL 300 has a transport length of 8.15 meters, a transport width of 2.92 meters, and a transport height of 3.47 meters.

What is the travel speed of the Doosan DL 300 wheel loader?

The Doosan DL 300 has a travel speed of 34 km/h.

What are the undercarriage specifications of the Doosan DL 300 wheel loader?

The Doosan DL 300 wheel loader is equipped with standard tyres sized 23.5 % L3.

What are the maneuverability specifications of the Doosan DL 300 wheel loader?

The Doosan DL 300 wheel loader has an articulated-frame steering mode and an outside turning radius of 6.35 meters.

What is the lifting force of the Doosan DL 300 wheel loader?

The Doosan DL 300 wheel loader has a lifting force of 162 kN.

What is the maximum discharge height of the Doosan DL 300 wheel loader?

The Doosan DL 300 wheel loader has a maximum discharge height of 2.9 meters.

What are the specifications of the primary work tool bucket on the Doosan DL 300 wheel loader?

The Doosan DL 300 wheel loader has a bucket with a capacity of 3 cubic meters, a minimum bucket capacity of 3 cubic meters, and a bucket width of 2.92 meters.
