DL 200-3 Doosan DL 200-3 Specifications & Technical Data (2013—2017)

The Doosan DL 200-3 is a wheel loader manufactured from 2013 to 2017. It has a weight of 12.2 tons and a transport length of 7.29 …

The Doosan DL 200-3 is a wheel loader manufactured from 2013 to 2017. It has a weight of 12.2 tons and a transport length of 7.29 meters. The bucket width is 2.55 meters and the maximum discharge height is 2.8 meters. It has a travel speed of 35 km/h and a transport width of 2.6 meters. The lifting force is 105 kN and the turning radius outside is 5.61 meters. The minimum bucket capacity is 1.9 cubic meters, and it is equipped with air conditioning.

DL 200-3

Years of manufacture: 2013—2017

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - DL 200-3 Doosan

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 12.2 t

Standard tyres: 20.5 R25

Bucket width: 2.55 m

Bucket capacity min.: 1.9 m³

Steering mode: KL

Transport length: 7.29 m

Transport width: 2.6 m

Travel speed: 35 km/h

Max. discharge height: 2.8 m

Turning radius outside: 5.61 m

Lifting force: 105 kN

Model series: DL

Engine manuf.: Doosan

Engine type: DL 06 K

Engine power: 119 kW

Displacement: 5.9 l

Revolutions at max torque: 1400 rpm

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Doosan DL 200-3 FAQ

When was the Doosan DL 200-3 manufactured?

The Doosan DL 200-3 was manufactured from 2013 to 2017.

How much does the Doosan DL 200-3 wheel loader weigh?

The Doosan DL 200-3 wheel loader weighs 12.2 tons.

What are the transport dimensions of the Doosan DL 200-3 wheel loader?

The Doosan DL 200-3 has a transport length of 7.29 meters and a transport width of 2.6 meters.

What is the travel speed of the Doosan DL 200-3 wheel loader?

The Doosan DL 200-3 has a travel speed of 35 km/h.

What are the standard tyres specifications of the Doosan DL 200-3 wheel loader?

The Doosan DL 200-3 wheel loader has standard tyres sized 20.5 R25.

What are the maneuverability specifications of the Doosan DL 200-3 wheel loader?

The Doosan DL 200-3 has an articulated-frame steering system and an outside turning radius of 5.61 meters.

What power rating information is available for the Doosan DL 200-3 wheel loader?

There is no power rating information available for the Doosan DL 200-3 wheel loader in the provided data.

What is the maximum discharge height of the Doosan DL 200-3?

The Doosan DL 200-3 has a maximum discharge height of 2.8 meters.

What are the bucket specifications of the Doosan DL 200-3 wheel loader?

The Doosan DL 200-3 wheel loader has a minimum bucket capacity of 1.9 cubic meters and a bucket width of 2.55 meters.

How much is a Doosan DL 200-3 Wheel loader (2013u20132017) worth?

The residual value of the Doosan DL 200-3 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
