986K Caterpillar 986K Specifications & Technical Data (2019—2026)

The Caterpillar 986K is a wheel loader model manufactured by Caterpillar since 2019. It has a weight of 52.93 tons and a transport…

The Caterpillar 986K is a wheel loader model manufactured by Caterpillar since 2019. It has a weight of 52.93 tons and a transport length of 10.67 meters. The bucket capacity is 5.4 cubic meters, with a bucket width of 3.81 meters. The maximum discharge height is 3.26 meters, and it has a travel speed of 39 km/h. The transport height is 4.1 meters. The machine is equipped with air conditioning.

986K

Years of manufacture: 2019—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 986K Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 52.93 t

Standard tyres: 35/65-33

Bucket width: 3.81 m

Bucket capacity: 5.4 m³

Bucket capacity min.: 5.4 m³

Transport length: 10.67 m

Transport height: 4.1 m

Travel speed: 39 km/h

Max. discharge height: 3.26 m

Engine manuf.: Caterpillar

Engine type: C15 Acert

Engine power: 278 kW

Displacement: 15.2 l

Revolutions at max torque: 1200 rpm

Max. torque: 2411 Nm

Cylinder bore x stroke: 137x171.5 mm

Emission level: Tier 4 f

More technical details, like: bucket capacity max., steering mode, transport width, turning radius outside, lifting force, model series, dimension lxwxh, no. of cylinders are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download specalog and datasheets (PDF)

Caterpillar 986K FAQ

When was the Caterpillar 986K manufactured?

The Caterpillar 986K was first produced in 2019.

How much does the Caterpillar 986K weigh?

The Caterpillar 986K weighs 52.93 tons.

What are the transport dimensions of the Caterpillar 986K wheel loader?

The Caterpillar 986K wheel loader has a transport length of 10.67 meters and a transport height of 4.1 meters.

What is the travel speed of the Caterpillar 986K wheel loader?

The Caterpillar 986K wheel loader has a travel speed of 39 km/h.

What are the undercarriage tyre specifications of the Caterpillar 986K wheel loader?

The Caterpillar 986K wheel loader is equipped with standard tyres sized 35/65-33.

What is the maximum discharge height of the Caterpillar 986K?

The Caterpillar 986K has a maximum discharge height of 3.26 meters.

What are the specifications of the bucket on the Caterpillar 986K wheel loader?

The bucket of the Caterpillar 986K has a capacity of 5.4 cubic meters and a width of 3.81 meters.
