972M Caterpillar 972M Specifications & Technical Data (2019—2026)

The Caterpillar 972M is a wheel loader manufactured since 2019. It has a weight of 24.9 tons and a transport length of 7.77 meters…

The Caterpillar 972M is a wheel loader manufactured since 2019. It has a weight of 24.9 tons and a transport length of 7.77 meters. The travel speed is 39.5 km/h, and the transport width is 3.01 meters. The transport height is 3.59 meters, and it has a lifting force of 196 kN. The bucket capacity ranges from 2.9 to 9.9 cubic meters.

972M

Years of manufacture: 2019—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 972M Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 24.9 t

Standard tyres: 26.5R25

Bucket capacity min.: 2.9 m³

Bucket capacity max.: 9.9 m³

Transport length: 7.77 m

Transport width: 3.01 m

Transport height: 3.59 m

Travel speed: 39.5 km/h

Lifting force: 196 kN

Engine manuf.: Caterpillar

Engine type: C9.3

Engine power: 222 kW

Displacement: 9.3 l

Revolutions at max torque: 1000 rpm

Max. torque: 1632 Nm

Emission level: Tier 3/ IIIA

More technical details, like: bucket width, bucket capacity, steering mode, max. discharge height, turning radius outside, model series, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download specalog and datasheets (PDF)

Caterpillar 972M FAQ

When was the Caterpillar 972M manufactured?

The Caterpillar 972M was first produced in 2019.

How much does the Caterpillar 972M wheel loader weigh?

The Caterpillar 972M wheel loader weighs 24.9 tons.

What are the transport dimensions of the Caterpillar 972M wheel loader?

The Caterpillar 972M has a transport length of 7.77 meters, a transport width of 3.01 meters, and a transport height of 3.59 meters.

What is the travel speed of the Caterpillar 972M wheel loader?

The Caterpillar 972M wheel loader has a travel speed of 39.5 km/h.

What is the standard tyre size of the Caterpillar 972M wheel loader?

The Caterpillar 972M wheel loader has standard tyres sized 26.5R25.

What are the power ratings of the Caterpillar 972M wheel loader?

The source data does not provide power ratings for the Caterpillar 972M wheel loader.

What are the bucket capacity specifications of the Caterpillar 972M wheel loader?

The Caterpillar 972M wheel loader has a bucket capacity ranging from 2.9 to 9.9 cubic meters.
