962M Caterpillar 962M Specifications & Technical Data (2014—2023)

The Caterpillar 962M is a wheel loader manufactured since 2014. It has a weight of 20.23 tons and a transport length of 7.23 meter…

The Caterpillar 962M is a wheel loader manufactured since 2014. It has a weight of 20.23 tons and a transport length of 7.23 meters. The bucket capacity is 3.8 cubic meters, with a width of 2.99 meters. The maximum discharge height is 2.95 meters. It has a travel speed of 39.5 km/h and a transport width of 2.82 meters. The transport height is 3.45 meters. The lifting force is 189 kN, and the turning radius outside is 6.44 meters. The bucket capacity is a minimum of 3.8 cubic meters. It is equipped with air conditioning and a swing loader.

962M

Years of manufacture: 2014—2023

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 962M Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 20.23 t

Standard tyres: 23.5R 25

Bucket width: 2.99 m

Bucket capacity: 3.8 m³

Bucket capacity min.: 3.8 m³

Steering mode: KL

Transport length: 7.23 m

Transport width: 2.82 m

Transport height: 3.45 m

Travel speed: 39.5 km/h

Max. discharge height: 2.95 m

Turning radius outside: 6.44 m

Lifting force: 189 kN

Engine manuf.: Caterpillar

Engine type: C7.1 Acert

Engine power: 202 kW

Displacement: 7 l

Max. torque: 694 Nm

Emission level: Tier 4 f

More technical details, like: bucket capacity max., model series, dimension lxwxh, revolutions at max torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: Yes
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download specalog and datasheets (PDF)

Caterpillar 962M FAQ

When was the Caterpillar 962M manufactured?

The Caterpillar 962M was manufactured from 2014 to 2023.

How much does the Caterpillar 962M wheel loader weigh?

The Caterpillar 962M wheel loader weighs 20.23 tons.

What are the transport dimensions of the Caterpillar 962M wheel loader?

The Caterpillar 962M has a transport length of 7.23 meters, a transport width of 2.82 meters, and a transport height of 3.45 meters.

What is the travel speed of the Caterpillar 962M wheel loader?

The Caterpillar 962M has a travel speed of 39.5 km/h.

What are the standard tyre specifications of the Caterpillar 962M wheel loader?

The Caterpillar 962M wheel loader is equipped with standard tyres sized 23.5R 25.

What are the maneuverability specifications of the Caterpillar 962M wheel loader?

The Caterpillar 962M wheel loader has an outside turning radius of 6.44 meters and uses articulated-frame steering.

What is the lifting force of the Caterpillar 962M?

The Caterpillar 962M has a lifting force of 189 kN. No power rating data is provided for this model in the source.

What is the material handling capacity of the Caterpillar 962M in terms of discharge height?

The Caterpillar 962M has a maximum discharge height of 2.95 meters.

What are the specifications of the bucket on the Caterpillar 962M wheel loader?

The Caterpillar 962M wheel loader has a bucket capacity of 3.8 cubic meters, a minimum bucket capacity of 3.8 cubic meters, and a bucket width of 2.99 meters.
