930M Caterpillar 930M Specifications & Technical Data (2017—2020)

The Caterpillar 930M is a wheel loader manufactured by Caterpillar from 2017 to 2020. It has a weight of 15.15 tons and a transpor…

The Caterpillar 930M is a wheel loader manufactured by Caterpillar from 2017 to 2020. It has a weight of 15.15 tons and a transport length of 7.75 meters. The maximum discharge height is 2.63 meters, while the transport width is 2.54 meters and the transport height is 3.74 meters. The turning radius outside is 5.4 meters. The bucket capacity ranges from a maximum of 5 cubic meters to a minimum of 2.1 cubic meters. This construction machine is equipped with a diesel particulate filter.

930M

Years of manufacture: 2017—2020

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 930M Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 15.15 t

Bucket capacity min.: 2.1 m³

Bucket capacity max.: 5 m³

Transport length: 7.75 m

Transport width: 2.54 m

Transport height: 3.74 m

Max. discharge height: 2.63 m

Turning radius outside: 5.4 m

Engine manuf.: Caterpillar

Engine type: C7.1 Acert

Engine power: 122 kW

Displacement: 7.01 l

Max. torque: 776 Nm

Emission level: Stage IV

More technical details, like: standard tyres, bucket width, bucket capacity, steering mode, travel speed, lifting force, model series, dimension lxwxh, revolutions at max torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: Yes
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download specalog and datasheets (PDF)

930M Caterpillar Specification for Europe (EN)

Caterpillar 930M FAQ

When was the Caterpillar 930M manufactured?

The Caterpillar 930M was manufactured from 2017 to 2020.

How much does the Caterpillar 930M wheel loader weigh?

The Caterpillar 930M wheel loader weighs 15.15 tons.

What are the transport dimensions of the Caterpillar 930M wheel loader?

The Caterpillar 930M has a transport length of 7.75 meters, a transport width of 2.54 meters, and a transport height of 3.74 meters.

What is the outside turning radius of the Caterpillar 930M wheel loader?

The Caterpillar 930M wheel loader has an outside turning radius of 5.4 meters.

What is the maximum discharge height of the Caterpillar 930M?

The Caterpillar 930M has a maximum discharge height of 2.63 meters.

What are the bucket capacity specifications of the Caterpillar 930M wheel loader?

The Caterpillar 930M wheel loader has a bucket capacity ranging from 2.1 to 5 cubic meters.
