    Caterpillar 930K Specifications & Technical Data (2013-2016)

    Rate this machine now!

    The 930K wheel loader model is manufactured by Caterpillar. Find and download detailed specs and data sheets for this machine here... Read more

    The 930K wheel loader model is manufactured by Caterpillar. Find and download detailed specs and data sheets for this machine here.

    This wheel loader is built to provide up to 116kW or 155 horse power, delivered from its powerful Caterpillar engine to the 13.8t 930K machine. The 930K is categorised in the biggest machine segment in the wheel loaders category. The measurements of the 930K are 2.54m x 7.53m x 3.34m. 20.5 R 25 is the size of standard tyres equipped on this Caterpillar 930K wheel loader. Operators can travel by 39km/h with this Wheel Loader The bucket capacity of 930K is 2.3m³, which is above average for this type of machine. 2.594m is the width of the bucket attached to this Caterpillar 930K wheel loader.

    Since 2013, this model has included Aircondition. It does not include telescopic, Quick hitch hydr. And Pivoting loader. Find detailed specifications and machine details in the original Caterpillar 930K datasheet. Available in English and German, LECTURA Specs offers a free download of highly detailed specifications and machine descriptions of this model.

    This model can be acquired for a list price between €211000 and €268000. Production of the 930K stopped in 2016. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

    Comparisons of the 930K Caterpillar with other wheel loader models reveal that, based on specifications and pricing, the model is similar to the Liebherr L 542 Z, Liebherr L 542 P as well as Liebherr L 542. Caterpillar currently produces 46 other wheel loaders, which range from 4.1t up to 240t - the most visited on LECTURA Specs are 988K, 966M, 926M. Want more detailed specifications? Download the latest Caterpillar 930K specs data sheet on LECTURA Specs today!

    Technical specs - 930K Caterpillar

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    • Weight 13.8 t
    • Standard tyres 20.5 R 25
    • Bucket width 2.594 m
    • Bucket capacity 2.3 m³
    • Bucket capacity min. 2.3 m³
    • Steering mode KL
    • Transport length 7.53 m
    • Transport width 2.54 m
    • Transport height 3.34 m
    • Travel speed 39 km/h
    • Turning radius outside 5.945 m
    • Engine manuf. Caterpillar
    • Engine type C7.1 Acert
    • Engine power 115 kW
    • Displacement 7.1 l
    • Max. torque 776 Nm
    • Cylinder bore x stroke 105x135 mm
    • Emission level Tier 4 f
    • Bucket capacity max. ###
    • Max. discharge height ###
    • Lifting force ###
    • Dimension lxwxh ###
    • Revolutions at max torque ###
    • No. of cylinders ###

    Basic model with ROPS cabin, std. shovel and teeth

    Special equipment

    • Diesel particulate filter
    • Swing loader
    • telescopic
    • Aircondition
    • Quick hitch hydr.
    • Quick hitch mech.
