926M Caterpillar 926M Specifications & Technical Data (2017—2026)

The Caterpillar 926M is a wheel loader manufactured since 2017. It has a weight of 12.99 tons and a transport length of 7.46 meter…

The Caterpillar 926M is a wheel loader manufactured since 2017. It has a weight of 12.99 tons and a transport length of 7.46 meters. The bucket capacity is 1.9 cubic meters, with a bucket width of 2.55 meters. The maximum discharge height is 2.9 meters. It has a travel speed of 40 km/h and a transport width of 2.79 meters. The transport height is 3.41 meters. The lifting force is 93 kN, and the turning radius outside is 5.93 meters. The machine has a maximum bucket capacity of 5 cubic meters and a minimum bucket capacity of 1.9 cubic meters. It is equipped with air conditioning and a diesel particulate filter.

926M

Years of manufacture: 2017—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 926M Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 12.99 t

Bucket width: 2.55 m

Bucket capacity: 1.9 m³

Bucket capacity min.: 1.9 m³

Bucket capacity max.: 5 m³

Transport length: 7.46 m

Transport width: 2.79 m

Transport height: 3.41 m

Travel speed: 40 km/h

Max. discharge height: 2.9 m

Turning radius outside: 5.93 m

Lifting force: 93 kN

Engine manuf.: Caterpillar

Engine type: C7.1 Acert

Engine power: 115 kW

Displacement: 7.1 l

Max. torque: 776 Nm

Cylinder bore x stroke: 105x135 mm

Emission level: Tier 4 f

More technical details, like: standard tyres, steering mode, model series, dimension lxwxh, revolutions at max torque, no. of cylinders are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: Yes
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download specalog and datasheets (PDF)

Caterpillar 926M FAQ

When was the Caterpillar 926M manufactured?

The Caterpillar 926M was first produced in 2017.

How much does the Caterpillar 926M wheel loader weigh?

The Caterpillar 926M wheel loader weighs 12.99 tons.

What are the transport dimensions of the Caterpillar 926M wheel loader?

The Caterpillar 926M has a transport length of 7.46 meters, a transport width of 2.79 meters, and a transport height of 3.41 meters.

What is the travel speed of the Caterpillar 926M wheel loader?

The Caterpillar 926M has a travel speed of 40 km/h.

What is the turning radius of the Caterpillar 926M wheel loader?

The Caterpillar 926M wheel loader has an outside turning radius of 5.93 meters.

What is the lifting force of the Caterpillar 926M wheel loader?

The Caterpillar 926M wheel loader has a lifting force of 93 kN.

What is the material handling capacity of the Caterpillar 926M in terms of discharge height?

The Caterpillar 926M has a maximum discharge height of 2.9 meters for material handling.

What are the specifications of the bucket on the Caterpillar 926M wheel loader?

The Caterpillar 926M wheel loader has a bucket with a capacity ranging from 1.9 to 5 cubic meters and a width of 2.55 meters.

How much is a Caterpillar 926M Wheel loader (2017u20132025) worth?

The residual value of the Caterpillar 926M depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
