926M Caterpillar 926M Specifications & Technical Data (2017—2020)

The Caterpillar 926M is a wheel loader manufactured by Caterpillar from 2017 to 2020. It has a weight of 13.13 tons and a transpor…

The Caterpillar 926M is a wheel loader manufactured by Caterpillar from 2017 to 2020. It has a weight of 13.13 tons and a transport length of 7.544 meters. The bucket capacity is 1.9 cubic meters, with a bucket width of 2.75 meters. The maximum discharge height is 2.81 meters. The transport width is 2.54 meters and the transport height is 3.71 meters. The turning radius outside is 5.4 meters. The machine is equipped with a diesel particulate filter. The bucket capacity ranges from a minimum of 1.9 cubic meters to a maximum of 5 cubic meters.

926M

Years of manufacture: 2017—2020

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 926M Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 13.13 t

Bucket width: 2.75 m

Bucket capacity: 1.9 m³

Bucket capacity min.: 1.9 m³

Bucket capacity max.: 5 m³

Transport length: 7.544 m

Transport width: 2.54 m

Transport height: 3.71 m

Max. discharge height: 2.81 m

Turning radius outside: 5.4 m

Engine manuf.: Caterpillar

Engine type: C7.1 Acert

Engine power: 115 kW

Displacement: 7.1 l

Max. torque: 776 Nm

Cylinder bore x stroke: 105x135 mm

Emission level: Tier 4 f

More technical details, like: standard tyres, steering mode, travel speed, lifting force, model series, dimension lxwxh, revolutions at max torque, no. of cylinders are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: Yes
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download specalog and datasheets (PDF)

Caterpillar 926M FAQ

When was the Caterpillar 926M manufactured?

The Caterpillar 926M was manufactured from 2017 to 2020.

How much does the Caterpillar 926M weigh?

The Caterpillar 926M weighs 13.13 tons.

What are the transport dimensions of the Caterpillar 926M wheel loader?

The Caterpillar 926M has a transport length of 7.54 meters, a transport width of 2.54 meters, and a transport height of 3.71 meters.

What is the turning radius of the Caterpillar 926M wheel loader?

The Caterpillar 926M has an outside turning radius of 5.4 meters.

What is the material handling capacity of the Caterpillar 926M in terms of discharge height?

The Caterpillar 926M has a maximum discharge height of 2.81 meters.

What are the specifications of the bucket on the Caterpillar 926M wheel loader?

The Caterpillar 926M wheel loader has a bucket with a capacity ranging from 1.9 to 5 cubic meters and a width of 2.75 meters.

How much is a Caterpillar 926M Wheel loader (2017u20132020) worth?

The residual value of the Caterpillar 926M depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
