Technical specs - 926 Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 13 t

Standard tyres: 20.5 R25

Bucket width: 2.55 m

Bucket capacity: 1.9 m³

Bucket capacity min.: 1.9 m³

Steering mode: KL

Turning radius outside: 5.4 m

Engine manuf.: Caterpillar

Engine type: C7.1 Acert

Engine power: 125 kW

Displacement: 7.1 l

Max. torque: 702 Nm

Cylinder bore x stroke: 105x135 mm

Emission level: EU V

More technical details, like: bucket capacity max., transport length, transport width, transport height, travel speed, max. discharge height, lifting force, model series, dimension lxwxh, revolutions at max torque, no. of cylinders are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: Yes
Swing loader: Yes
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download specalog and datasheets (PDF)

Caterpillar 926 FAQ

When was the Caterpillar 926 manufactured?

The Caterpillar 926 was first produced in 2023.

How much does the Caterpillar 926 wheel loader weigh?

The Caterpillar 926 wheel loader weighs 13 tons.

What is the standard tyre size of the Caterpillar 926 wheel loader?

The Caterpillar 926 wheel loader has standard tyres sized 20.5 R25.

What are the maneuverability specifications of the Caterpillar 926 wheel loader?

The Caterpillar 926 wheel loader has an outside turning radius of 5.4 meters and uses articulated-frame steering.

What are the primary work tool bucket specifications of the Caterpillar 926 wheel loader?

The Caterpillar 926 wheel loader has a bucket capacity of 1.9 cubic meters, a minimum bucket capacity of 1.9 cubic meters, and a bucket width of 2.55 meters.
