914K Caterpillar 914K Specifications & Technical Data (2014—2017)

The Caterpillar 914K is a wheel loader manufactured from 2014 to 2017. It has a weight of 8.1 tons and a transport length of 6.36 …

The Caterpillar 914K is a wheel loader manufactured from 2014 to 2017. It has a weight of 8.1 tons and a transport length of 6.36 meters. The bucket capacity is 1.5 cubic meters, with a width of 2.401 meters. The maximum discharge height is 3.32 meters. It has a travel speed of 40 km/h and a transport width of 2.26 meters. The transport height is 3.28 meters and the turning radius outside is 5.18 meters. The minimum bucket capacity is also 1.5 cubic meters.

914K

Years of manufacture: 2014—2017

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 914K Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 8.1 t

Standard tyres: 17.5-25

Bucket width: 2.401 m

Bucket capacity: 1.5 m³

Bucket capacity min.: 1.5 m³

Steering mode: KL

Transport length: 6.36 m

Transport width: 2.26 m

Transport height: 3.28 m

Travel speed: 40 km/h

Max. discharge height: 3.32 m

Turning radius outside: 5.18 m

Engine manuf.: Caterpillar

Engine type: C3.8 DIT

Engine power: 72 kW

Displacement: 3.8 l

More technical details, like: bucket capacity max., lifting force, model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download specalog and datasheets (PDF)

914K Caterpillar Specification for Europe (en)

Caterpillar 914K FAQ

When was the Caterpillar 914K manufactured?

The Caterpillar 914K was manufactured from 2014 to 2017.

How much does the Caterpillar 914K wheel loader weigh?

The Caterpillar 914K wheel loader weighs 8.1 tons.

What are the transport dimensions of the Caterpillar 914K wheel loader?

The Caterpillar 914K has a transport length of 6.36 meters, a transport width of 2.26 meters, and a transport height of 3.28 meters.

What is the travel speed of the Caterpillar 914K wheel loader?

The Caterpillar 914K wheel loader has a travel speed of 40 km/h.

What are the undercarriage specifications of the Caterpillar 914K wheel loader?

The Caterpillar 914K wheel loader is equipped with standard tyres sized 17.5-25.

What are the maneuverability specifications of the Caterpillar 914K wheel loader?

The Caterpillar 914K wheel loader has an articulated-frame steering system and an outside turning radius of 5.18 meters.

What is the maximum discharge height of the Caterpillar 914K?

The Caterpillar 914K has a maximum discharge height of 3.32 meters.

What are the specifications of the bucket on the Caterpillar 914K wheel loader?

The Caterpillar 914K wheel loader has a bucket capacity of 1.5 cubic meters, a minimum bucket capacity of 1.5 cubic meters, and a bucket width of 2.4 meters.
