721 E Case 721 E Specifications & Technical Data (2007—2012)

Model rating: 8,00 / 10

The Case 721 E is a wheel loader manufactured from 2007 to 2012. It has a weight of 14.5 tons and a transport length of 7.86 meter…

The Case 721 E is a wheel loader manufactured from 2007 to 2012. It has a weight of 14.5 tons and a transport length of 7.86 meters. The bucket capacity is 2.4 cubic meters, with a bucket width of 2.474 meters. The maximum discharge height is 4 meters, and it has a travel speed of 38 km/h. The transport width is 2.54 meters, and the transport height is 3.4 meters. It has a lifting force of 135 kN and a turning radius outside of 12.64 meters. Special equipment includes air conditioning and a quick hitch mechanism.

721 E

Years of manufacture: 2007—2012

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Reviews
Transport
News

Technical specs - 721 E Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 14.5 t

Standard tyres: 20.5 R 25

Bucket width: 2.474 m

Bucket capacity: 2.4 m³

Bucket capacity min.: 2.4 m³

Steering mode: KL

Transport length: 7.86 m

Transport width: 2.54 m

Transport height: 3.4 m

Travel speed: 38 km/h

Max. discharge height: 4 m

Turning radius outside: 12.64 m

Lifting force: 135 kN

Model series: E

Engine manuf.: Case

Engine type: 667TA-EED

Engine power: 137 kW

Displacement: 6.7 l

Revolutions at max torque: 1900 rpm

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: Yes

Download datasheets (PDF)

Case 721 E FAQ

When was the Case 721 E manufactured?

The Case 721 E was manufactured from 2007 to 2012.

How much does the Case 721 E wheel loader weigh?

The Case 721 E wheel loader weighs 14.5 tons.

What are the transport dimensions of the Case 721 E wheel loader?

The Case 721 E wheel loader has a transport length of 7.86 meters, a transport width of 2.54 meters, and a transport height of 3.4 meters.

What is the travel speed of the Case 721 E wheel loader?

The Case 721 E wheel loader has a travel speed of 38 km/h.

What are the standard tyre specifications of the Case 721 E wheel loader?

The Case 721 E wheel loader is equipped with standard tyres sized 20.5 R 25.

What are the maneuverability specifications of the Case 721 E wheel loader?

The Case 721 E wheel loader has an articulated-frame steering system and an outside turning radius of 12.64 meters.

What is the lifting force of the Case 721 E wheel loader?

The Case 721 E wheel loader has a lifting force of 135 kN. No power rating data is provided in the source.

What is the material handling capacity of the Case 721 E in terms of discharge height?

The Case 721 E has a maximum discharge height of 4 meters for material handling.

What are the bucket specifications of the Case 721 E wheel loader?

The Case 721 E wheel loader has a bucket capacity of 2.4 cubic meters, a minimum bucket capacity of 2.4 cubic meters, and a bucket width of 2.47 meters.

How much is a Case 721 E Wheel loader (2007u20132012) worth?

The residual value of the Case 721 E depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Reviews

Model rating: 8,00 / 10

Case 721 E user from Colombia

Very good machine

Case 721 E user from United States

Case was always user friendly and easy to maintain. Light in the rear though, you need extra counterweight for carrying its full capacity.
