621 F XT Case 621 F XT Specifications & Technical Data (2013—2016)

The Case 621 F XT is a wheel loader manufactured by Case from 2013 to 2016. It has a weight of 13 tons and a transport length of 7…

The Case 621 F XT is a wheel loader manufactured by Case from 2013 to 2016. It has a weight of 13 tons and a transport length of 7.83 meters. The bucket capacity is 2.4 cubic meters, with a bucket width of 2.6 meters. The travel speed of this machine is 40 km/h. It has a transport width of 2.52 meters and a transport height of 3.4 meters. The bucket capacity minimum is also 2.4 cubic meters. Special equipment includes air conditioning and a quick hitch mechanism.

621 F XT

Years of manufacture: 2013—2016

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 621 F XT Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 13 t

Standard tyres: 20.5-25 XHQA

Bucket width: 2.6 m

Bucket capacity: 2.4 m³

Bucket capacity min.: 2.4 m³

Steering mode: KL

Transport length: 7.83 m

Transport width: 2.52 m

Transport height: 3.4 m

Travel speed: 40 km/h

Model series: F

Engine manuf.: CNH

Engine type: 667TA-EDB

Engine power: 128 kW

Displacement: 6.7 l

Revolutions at max torque: 2000 rpm

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: Yes

Download datasheets (PDF)

Case 621 F XT FAQ

When was the Case 621 F XT manufactured?

The Case 621 F XT was manufactured from 2013 to 2016.

How much does the Case 621 F XT wheel loader weigh?

The Case 621 F XT wheel loader weighs 13 tons.

What are the transport dimensions of the Case 621 F XT wheel loader?

The Case 621 F XT has a transport length of 7.83 meters, a transport width of 2.52 meters, and a transport height of 3.4 meters.

What is the travel speed of the Case 621 F XT wheel loader?

The Case 621 F XT has a travel speed of 40 km/h.

What are the undercarriage tyre specifications of the Case 621 F XT wheel loader?

The Case 621 F XT wheel loader is equipped with standard tyres sized 20.5-25 XHQA.

What is the steering mode of the Case 621 F XT wheel loader?

The Case 621 F XT wheel loader has articulated-frame steering.

What are the specifications of the bucket on the Case 621 F XT wheel loader?

The Case 621 F XT wheel loader has a bucket capacity of 2.4 cubic meters, a minimum bucket capacity of 2.4 cubic meters, and a bucket width of 2.6 meters.

How much is a Case 621 F XT Wheel loader (2013u20132016) worth?

The residual value of the Case 621 F XT depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
