570N EP Case 570N EP Specifications & Technical Data (2021—2026)

The Case 570N EP is a wheel loader manufactured since 2021. It has a weight of 6.58 tons and a transport length of 5.15 meters. Th…

The Case 570N EP is a wheel loader manufactured since 2021. It has a weight of 6.58 tons and a transport length of 5.15 meters. The bucket width is 2.08 meters and the maximum discharge height is 2.63 meters. It has a travel speed of 38.6 km/h and a transport width of 2.07 meters. The transport height is 2.74 meters, and the lifting force is 42.7 kN. The turning radius outside is 4.18 meters.

570N EP

Years of manufacture: 2021—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 570N EP Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 6.58 t

Standard tyres: 19.5 L x 24.0 Tires

Bucket width: 2.08 m

Transport length: 5.15 m

Transport width: 2.07 m

Transport height: 2.74 m

Travel speed: 38.6 km/h

Max. discharge height: 2.63 m

Turning radius outside: 4.18 m

Lifting force: 42.7 kN

Model series: N

Engine manuf.: FPT

Engine type: F5HFL463D

Engine power: 54 kW

Displacement: 3.4 l

Revolutions at max torque: 1400 rpm

Max. torque: 310 Nm

No. of cylinders: 4

Cylinder bore x stroke: 99x110 mm

Emission level: Tier 4f

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

570N EP Case Specification for Global (EN)

Case 570N EP FAQ

When was the Case 570N EP manufactured?

The Case 570N EP was first produced in 2021.

How much does the Case 570N EP weigh?

The Case 570N EP weighs 6.58 tons.

What are the transport dimensions of the Case 570N EP wheel loader?

The Case 570N EP has a transport length of 5.15 meters, a transport width of 2.07 meters, and a transport height of 2.74 meters.

What is the travel speed of the Case 570N EP wheel loader?

The Case 570N EP has a travel speed of 38.6 km/h.

What are the standard tyre specifications for the Case 570N EP wheel loader?

The Case 570N EP wheel loader has standard tyres sized 19.5 L x 24.0 Tires.

What is the turning radius of the Case 570N EP wheel loader?

The Case 570N EP wheel loader has an outside turning radius of 4.18 meters.

What are the power ratings of the Case 570N EP wheel loader?

There is no power rating data available for the Case 570N EP wheel loader in the provided information.

What is the maximum discharge height of the Case 570N EP?

The Case 570N EP has a maximum discharge height of 2.63 meters.

What is the bucket width of the Case 570N EP wheel loader?

The bucket width of the Case 570N EP wheel loader is 2.08 meters.

How much is a Case 570N EP Wheel loader (2021u20132025) worth?

The residual value of the Case 570N EP depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
