221F Case 221F Specifications & Technical Data (2014—2020)

The Case 221F is a wheel loader manufactured from 2014 to 2020. It has a weight of 6.03 tons and a transport length of 5.62 meters…

The Case 221F is a wheel loader manufactured from 2014 to 2020. It has a weight of 6.03 tons and a transport length of 5.62 meters. The bucket capacity is 1.2 cubic meters, with a bucket width of 2.05 meters. The maximum discharge height is 2.6 meters, and it has a travel speed of 33 km/h. The transport width and height are both 2.05 and 2.63 meters, respectively. It has a lifting force of 55 kN and a turning radius outside of 3.99 meters. Special equipment includes a quick hitch hydraulic mechanism.

221F

Years of manufacture: 2014—2020

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 221F Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 6.03 t

Standard tyres: 12.5-20

Bucket width: 2.05 m

Bucket capacity: 1.2 m³

Bucket capacity min.: 1.2 m³

Steering mode: KL

Transport length: 5.62 m

Transport width: 2.05 m

Transport height: 2.63 m

Travel speed: 33 km/h

Max. discharge height: 2.6 m

Turning radius outside: 3.99 m

Lifting force: 55 kN

Model series: F

Engine manuf.: CNH

Engine type: F5H

Engine power: 55 kW

Displacement: 3.4 l

Revolutions at max torque: 2100 rpm

Max. torque: 316 Nm

Emission level: Stage IIIB / Tier 4 ﬁnal

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Case 221F FAQ

When was the Case 221F manufactured?

The Case 221F was manufactured from 2014 to 2020.

How much does the Case 221F wheel loader weigh?

The Case 221F wheel loader weighs 6.03 tons.

What are the transport dimensions of the Case 221F wheel loader?

The Case 221F has a transport length of 5.62 meters, a transport width of 2.05 meters, and a transport height of 2.63 meters.

What is the travel speed of the Case 221F wheel loader?

The Case 221F wheel loader has a travel speed of 33 km/h.

What are the undercarriage tyre specifications of the Case 221F wheel loader?

The Case 221F wheel loader is equipped with standard tyres sized 12.5-20.

What are the maneuverability specifications of the Case 221F wheel loader?

The Case 221F wheel loader has an articulated-frame steering system and an outside turning radius of 3.99 meters.

What is the power rating of the Case 221F wheel loader?

The power rating of the Case 221F wheel loader is not provided in the available data.

What is the maximum discharge height of the Case 221F wheel loader?

The Case 221F wheel loader has a maximum discharge height of 2.6 meters.

What are the bucket specifications of the Case 221F wheel loader?

The Case 221F wheel loader has a bucket capacity of 1.2 cubic meters, a minimum bucket capacity of 1.2 cubic meters, and a bucket width of 2.05 meters.
