L705D Bell L705D Specifications & Technical Data (2006—2012)

The Bell L705D is a wheel loader manufactured by Bell from 2006 to 2012. It has a weight of 6 tons and a transport length of 6.139…

The Bell L705D is a wheel loader manufactured by Bell from 2006 to 2012. It has a weight of 6 tons and a transport length of 6.139 meters. The bucket width is 2 meters and it has a maximum discharge height of 3.365 meters. The travel speed of the wheel loader is 30 km/h. It has a transport width of 2.2 meters and a transport height of 2.802 meters. The turning radius outside is 3.777 meters. The bucket capacity is maximum 1 cubic meter. The special equipment included in this construction machine is air conditioning.

L705D

Years of manufacture: 2006—2012

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - L705D Bell

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 6 t

Standard tyres: 405/70R20

Bucket width: 2 m

Bucket capacity max.: 1 m³

Transport length: 6.139 m

Transport width: 2.2 m

Transport height: 2.802 m

Travel speed: 30 km/h

Max. discharge height: 3.365 m

Turning radius outside: 3.777 m

Engine manuf.: John Deere

Engine type: POWERTECH 5030T

Engine power: 54 kW

Displacement: 3 l

Revolutions at max torque: 1500 rpm

Max. torque: 264 Nm

No. of cylinders: 5

Emission level: Tier II

More technical details, like: bucket capacity, bucket capacity min., steering mode, lifting force, model series, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

L705D Bell Specification for North America (EN)

Bell L705D FAQ

When was the Bell L705D manufactured?

The Bell L705D was manufactured from 2006 to 2012.

How much does the Bell L705D wheel loader weigh?

The Bell L705D wheel loader weighs 6 tons.

What are the transport dimensions of the Bell L705D wheel loader?

The Bell L705D has a transport length of 6.14 meters, a transport width of 2.2 meters, and a transport height of 2.8 meters.

What is the travel speed of the Bell L705D wheel loader?

The Bell L705D wheel loader has a travel speed of 30 km/h.

What are the standard tyre specifications for the Bell L705D wheel loader's undercarriage?

The Bell L705D wheel loader is equipped with standard tyres sized 405/70R20 on its undercarriage.

What is the outside turning radius of the Bell L705D wheel loader?

The Bell L705D wheel loader has an outside turning radius of 3.777 meters.

What is the maximum discharge height of the Bell L705D?

The Bell L705D has a maximum discharge height of 3.37 meters.

What are the specifications of the bucket on the Bell L705D wheel loader?

The Bell L705D wheel loader has a bucket with a maximum capacity of 1 cubic meter and a width of 2 meters.
