AX 1000 Ahlmann AX 1000 Specifications & Technical Data (2010—2012)

The Ahlmann AX 1000 is a wheel loader manufactured by Ahlmann from 2010 to 2012. It has a weight of 5.8 tons and a transport lengt…

The Ahlmann AX 1000 is a wheel loader manufactured by Ahlmann from 2010 to 2012. It has a weight of 5.8 tons and a transport length of 5.35 meters. The bucket capacity is 1 cubic meter, with a maximum discharge height of 2.86 meters. It has a travel speed of 20 km/h and a transport width of 1.85 meters. The transport height is 2.45 meters. The lifting force is 44.5 kN. The machine is equipped with a quick hitch hydr. for special operations.

AX 1000

Years of manufacture: 2010—2012

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - AX 1000 Ahlmann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.8 t

Standard tyres: 365/70 R18

Bucket capacity: 1 m³

Bucket capacity min.: 1 m³

Steering mode: KL

Transport length: 5.35 m

Transport width: 1.85 m

Transport height: 2.45 m

Travel speed: 20 km/h

Max. discharge height: 2.86 m

Lifting force: 44.5 kN

Model series: AX

Engine manuf.: John Deere

Engine type: 4024HF295

Engine power: 49 kW

Revolutions at max torque: 2000 rpm

More technical details, like: bucket width, bucket capacity max., turning radius outside, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Ahlmann AX 1000 FAQ

When was the Ahlmann AX 1000 manufactured?

The Ahlmann AX 1000 was manufactured from 2010 to 2012.

How much does the Ahlmann AX 1000 weigh?

The Ahlmann AX 1000 weighs 5.8 tons.

What are the transport dimensions of the Ahlmann AX 1000 wheel loader?

The Ahlmann AX 1000 has a transport length of 5.35 meters, a transport width of 1.85 meters, and a transport height of 2.45 meters.

What is the travel speed of the Ahlmann AX 1000 wheel loader?

The Ahlmann AX 1000 has a travel speed of 20 km/h.

What are the standard tyre specifications of the Ahlmann AX 1000?

The Ahlmann AX 1000 is equipped with standard tyres sized 365/70 R18.

What is the steering mode of the Ahlmann AX 1000?

The Ahlmann AX 1000 has articulated-frame steering.

What is the lifting force of the Ahlmann AX 1000 wheel loader?

The Ahlmann AX 1000 has a lifting force of 44.5 kN.

What is the maximum discharge height of the Ahlmann AX 1000 wheel loader?

The Ahlmann AX 1000 wheel loader has a maximum discharge height of 2.86 meters.

What is the bucket capacity of the Ahlmann AX 1000 wheel loader?

The Ahlmann AX 1000 wheel loader has a bucket capacity of 1 cubic meter.
