AS 900 Ahlmann AS 900 Specifications & Technical Data (2010—2012)

The Ahlmann AS 900 is a wheel loader manufactured from 2010 to 2012. It has a weight of 6.6 tons and a transport length of 5.59 me…

The Ahlmann AS 900 is a wheel loader manufactured from 2010 to 2012. It has a weight of 6.6 tons and a transport length of 5.59 meters. The maximum discharge height is 3.13 meters, and it can travel at a speed of 30 km/h. The transport width is 2.1 meters, and the transport height is 2.83 meters. The bucket capacity ranges from 0.7 to 1.2 cubic meters. Special equipment includes a quick hitch hydraulic system and a swing loader.

AS 900

Years of manufacture: 2010—2012

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - AS 900 Ahlmann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 6.6 t

Standard tyres: 14.5-20

Bucket capacity min.: 0.7 m³

Bucket capacity max.: 1.2 m³

Steering mode: AL

Transport length: 5.59 m

Transport width: 2.1 m

Transport height: 2.83 m

Travel speed: 30 km/h

Max. discharge height: 3.13 m

Model series: AS

Engine manuf.: Cummins

Engine type: B3.3ST

Engine power: 55 kW

Displacement: 3.3 l

Revolutions at max torque: 1600 rpm

More technical details, like: bucket width, bucket capacity, turning radius outside, lifting force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: Yes
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Ahlmann AS 900 FAQ

When was the Ahlmann AS 900 manufactured?

The Ahlmann AS 900 was manufactured from 2010 to 2012.

How much does the Ahlmann AS 900 wheel loader weigh?

The Ahlmann AS 900 wheel loader weighs 6.6 tons.

What are the transport dimensions of the Ahlmann AS 900 wheel loader?

The Ahlmann AS 900 has a transport length of 5.59 meters, a transport width of 2.1 meters, and a transport height of 2.83 meters.

What is the travel speed of the Ahlmann AS 900 wheel loader?

The Ahlmann AS 900 has a travel speed of 30 km/h.

What is the standard tyre size of the Ahlmann AS 900 wheel loader?

The Ahlmann AS 900 wheel loader has standard tyres sized 14.5-20 inches.

What is the steering mode of the Ahlmann AS 900?

The Ahlmann AS 900 has an all-wheel steering mode.

What is the maximum discharge height of the Ahlmann AS 900?

The Ahlmann AS 900 has a maximum discharge height of 3.13 meters.

What are the bucket capacity specifications of the Ahlmann AS 900 wheel loader?

The Ahlmann AS 900 wheel loader has a bucket capacity ranging from 0.7 to 1.2 cubic meters.

How much is a Ahlmann AS 900 Wheel loader (2010u20132012) worth?

The residual value of the Ahlmann AS 900 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
