AS 210 e Ahlmann AS 210 e Specifications & Technical Data (2008—2012)

The Ahlmann AS 210 e is a wheel loader manufactured by Ahlmann from 2008 to 2012. It has a weight of 14.5 tons and a transport len…

The Ahlmann AS 210 e is a wheel loader manufactured by Ahlmann from 2008 to 2012. It has a weight of 14.5 tons and a transport length of 7.155 meters. The bucket capacity is 2.1 cubic meters, and it has a maximum discharge height of 3.42 meters. The travel speed of this wheel loader is 20 km/h. It has a transport width of 2.605 meters and a transport height of 3.155 meters. The lifting force of the AS 210 e is 106 kN. It is equipped with special features such as a quick hitch hydr. and a swing loader.

AS 210 e

Years of manufacture: 2008—2012

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - AS 210 e Ahlmann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 14.5 t

Standard tyres: 20.5-25

Bucket capacity: 2.1 m³

Bucket capacity min.: 2.1 m³

Steering mode: AL

Transport length: 7.155 m

Transport width: 2.605 m

Transport height: 3.155 m

Travel speed: 20 km/h

Max. discharge height: 3.42 m

Lifting force: 106 kN

Model series: AS

More technical details, like: bucket width, bucket capacity max., turning radius outside, engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: Yes
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Ahlmann AS 210 e FAQ

When was the Ahlmann AS 210 e manufactured?

The Ahlmann AS 210 e was manufactured from 2008 to 2012.

How much does the Ahlmann AS 210 e wheel loader weigh?

The Ahlmann AS 210 e wheel loader weighs 14.5 tons.

What are the transport dimensions of the Ahlmann AS 210 e wheel loader?

The Ahlmann AS 210 e has a transport length of 7.16 meters, a transport width of 2.61 meters, and a transport height of 3.16 meters.

What is the travel speed of the Ahlmann AS 210 e wheel loader?

The Ahlmann AS 210 e has a travel speed of 20 km/h.

What are the undercarriage specifications of the Ahlmann AS 210 e?

The Ahlmann AS 210 e is equipped with standard tyres sized 20.5-25.

What is the steering mode of the Ahlmann AS 210 e?

The Ahlmann AS 210 e has an all-wheel steering mode.

What is the lifting force rating of the Ahlmann AS 210 e wheel loader?

The Ahlmann AS 210 e wheel loader has a lifting force of 106 kN.

What is the maximum discharge height of the Ahlmann AS 210 e wheel loader?

The Ahlmann AS 210 e has a maximum discharge height of 3.42 meters.

What is the bucket capacity of the Ahlmann AS 210 e wheel loader?

The Ahlmann AS 210 e has a bucket capacity of 2.1 cubic meters.

How much is a Ahlmann AS 210 e Wheel loader (2008u20132012) worth?

The residual value of the Ahlmann AS 210 e depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
