Wacker Neuson DW60 LRC Specifications & Technical Data (2014-2019)

Technical specs - DW60 LRC Wacker Neuson

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.5 t

Standard tyres: 400/55R22.5

Net load: 6 t

Dump capacity: 2.65 m³

Dumper type: V

Transport length: 5 m

Transport width: 2.33 m

Transport height: 3.11 m

Travel speed: 25 km/h

Model series: DW

Engine manuf.: Perkins

Engine type: 1104D

Engine power: 62.5 kW

Displacement: 4.4 l

Revolutions at max torque: 2200 rpm

Emission level: III A

More technical details, like: loading height, turning radius outside, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, model type, driveline, rops, fops, engine manufacturer, engine model...

More technical details, like: loading height, turning radius outside, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, model type, driveline, rops, fops, engine manufacturer, engine model, rated speed, engine output, fuel, drive, tyre size - front, tyre size - rear, service type, height over rops, width, overall length, wheelbase, ground clearance, width - front tyres, width - rear tyres, width - skip, height over skip - untipped, turning radius - outside, chassis articulation, payload - heaped, payload - struck, payload - water, skip payload, travel speed - maximum, operating weight - unladen are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Heated dump body: No
All-wheel drive: Yes
Track: No
Aircondition: No

Download datasheets (PDF)

Wacker Neuson DW60 LRC FAQ

When was the Wacker Neuson DW60 LRC manufactured?

The Wacker Neuson DW60 LRC was manufactured from 2014 to 2019.

How much does the Wacker Neuson DW60 LRC weigh?

The Wacker Neuson DW60 LRC weighs 4.5 tons.

What are the transport dimensions of the Wacker Neuson DW60 LRC?

The Wacker Neuson DW60 LRC has a transport length of 5 meters, a transport width of 2.33 meters, and a transport height of 3.11 meters.

What is the travel speed of the Wacker Neuson DW60 LRC?

The Wacker Neuson DW60 LRC has a travel speed of 25 km/h.

What are the undercarriage tyre specifications of the Wacker Neuson DW60 LRC?

The Wacker Neuson DW60 LRC is equipped with standard tyres sized 400/55R22.5.

What is the material handling capacity of the Wacker Neuson DW60 LRC?

The Wacker Neuson DW60 LRC has a net load capacity of 6 tons and a dump capacity of 2.65 cubic meters.

How much is a Wacker Neuson DW60 LRC Wheel dumper (2014u20132019) worth?

The residual value of the Wacker Neuson DW60 LRC depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
