Wacker Neuson DW60-2 Specifications & Technical Data (2021-2023)

Rate this machine now!

Weight: 4.016t – Standard tyres: 405/70-20 – Net load: 6t – Dump capacity: 2.7m³ – Dumper type: R – Transport length: 4.496m

Technical specs - DW60-2 Wacker Neuson

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Weight 4.016 t
  • Standard tyres 405/70-20
  • Net load 6 t
  • Dump capacity 2.7 m³
  • Dumper type R
  • Transport length 4.496 m
  • Transport width 2.328 m
  • Transport height 3.208 m
  • Travel speed 25 km/h
  • Model series DW
  • Engine manuf. Deutz
  • Engine type TD 2.2
  • Engine power 44.5 kW
  • Displacement 2.194 l
  • No. of cylinders 3
  • Emission level V

More technical details, like: loading height, turning radius outside, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

  • Diesel particulate filter
  • Heated dump body
  • All-wheel drive
  • Track
  • Aircondition
