Technical specs - 1601 Wacker Neuson
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 1.261 t
- Standard tyres
- 10.00/75x15.3
- Net load
- 1.5 t
- Dump capacity
- 0.65 m³
- Dumper type
- H
- Transport length
- 3 m
- Transport width
- 1.305 m
- Transport height
- 2.55 m
- Travel speed
- 16 km/h
- Loading height
- 1.345 m
- Turning radius outside
- 3.3 m
- Model series
- 1000
- Engine manuf.
- Yanmar
- Engine type
- 3TNV76
- Engine power
- 18.9 kW
- Displacement
- 1.16 l
- Revolutions at max torque
- 3000 rpm
- No. of cylinders
- 3
- Emission level
- V
More technical details, like: dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin and std. trough
Special equipment
- Diesel particulate filter
-
No
- Heated dump body
-
No
- All-wheel drive
-
No
- Track
-
No
- Aircondition
-
No
Download datasheets (PDF)
