NC SW9 NC-Engineering NC SW9 Specifications & Technical Data (2016—2026)

Standard tyres: 500/60 R22.5 – Net load: 9t – Dump capacity: 4.427m³ – Transport length: 4.972m – Transport width: 2.428m – Transport height: 2.371m

Technical specs - NC SW9 NC-Engineering

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Standard tyres
500/60 R22.5
Net load
9 t
Dump capacity
4.427 m³
Transport length
4.972 m
Transport width
2.428 m
Transport height
2.371 m
Travel speed
32 km/h
Loading height
2.022 m
Turning radius outside
12.34 m
Model series
SW
Engine manuf.
JCB
Engine type
444T
Engine power
85 kW
Displacement
4.4 l
Revolutions at max torque
1300 rpm
Max. torque
440 Nm
Emission level
Strage IIIA

More technical details, like: weight, dumper type, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter
No
Heated dump body
No
All-wheel drive
Yes
Track
No
Aircondition
No
