NC-Engineering NC SW1930
- Weight:
- 2.43 t
- Standard tyres:
- 11.5/80-15.3 12PR
- Net load:
- 3 t
- Dump capacity:
- 1.663 m³
NC SW1930 NC-Engineering NC SW1930 Specifications & Technical Data (2025—2026)
Technical specs - NC SW1930 NC-Engineering
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 2.43 t
- Standard tyres
- 11.5/80-15.3 12PR
- Net load
- 3 t
- Dump capacity
- 1.663 m³
- Transport length
- 4.106 m
- Transport width
- 1.73 m
- Transport height
- 1.914 m
- Travel speed
- 20 km/h
- Loading height
- 1.436 m
- Turning radius outside
- 8.7 m
- Model series
- SW
- Engine manuf.
- Kubota
- Engine type
- D1105
- Engine power
- 18.2 kW
- Displacement
- 1.1 l
- Revolutions at max torque
- 2200 rpm
- Max. torque
- 72 Nm
- Emission level
- Stage V/Tier 4
More technical details, like: dumper type, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin and std. trough
Special equipment
- Diesel particulate filter
-
No
- Heated dump body
-
No
- All-wheel drive
-
Yes
- Track
-
No
- Aircondition
-
No
Download datasheets (PDF)
