TA9P Mecalac TA9P Specifications & Technical Data (2017—2020)
Technical specs - TA9P Mecalac
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 4.92 t
- Standard tyres
- 500-60-22.5 16PR
- Net load
- 9 t
- Dump capacity
- 4.587 m³
- Dumper type
- V
- Transport length
- 4.484 m
- Transport width
- 2.5 m
- Transport height
- 3.668 m
- Travel speed
- 24.8 km/h
- Loading height
- 0.49 m
- Turning radius outside
- 5.994 m
- Model series
- TA
- Engine manuf.
- JCB
- Engine type
- EcoMax
- Engine power
- 55 kW
- Displacement
- 4.4 l
- Max. torque
- 400 Nm
- No. of cylinders
- 4
- Emission level
- EU 3B / Tier 4 Final
More technical details, like: dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin and std. trough
Special equipment
- Diesel particulate filter
-
No
- Heated dump body
-
No
- All-wheel drive
-
No
- Track
-
No
- Aircondition
-
No
Download datasheets (PDF)
