Technical specs - TA3 Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.28 t

Standard tyres: 295/80x15.3 10ply

Net load: 3 t

Dump capacity: 1.95 m³

Dumper type: V

Transport length: 4 m

Transport width: 1.957 m

Transport height: 2.92 m

Travel speed: 19 km/h

Loading height: 0.208 m

Turning radius outside: 4.711 m

Model series: TA

Engine manuf.: Kubota

Engine type: V2203M

Engine power: 32.4 kW

Displacement: 2.197 l

Emission level: III A

More technical details, like: dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, model type, driveline, rops, fops, telematics available, platform, fleet management, health monitoring, security, engine manufacturer, engine model, rated speed, engine output, torque, fuel, drive, tyre size - front, tyre size - rear, service type, height over rops, width, overall length, wheelbase, ground clearance, width - front tyres, width - rear tyres, skip lip height - untipped, turning radius - outside, chassis articulation, payload - heaped, payload - struck, payload - water, skip payload, travel speed - maximum, operating weight - unladen are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Heated dump body: No
All-wheel drive: Yes
Track: No
Aircondition: No

Download datasheets (PDF)

Mecalac TA3 FAQ

When was the Mecalac TA3 manufactured?

The Mecalac TA3 was manufactured from 2017 to 2020.

How much does the Mecalac TA3 wheel dumper weigh?

The Mecalac TA3 wheel dumper weighs 2.28 tons.

What are the transport dimensions of the Mecalac TA3 wheel dumper?

The Mecalac TA3 has a transport length of 4 meters, a transport width of 1.96 meters, and a transport height of 2.92 meters.

What is the travel speed of the Mecalac TA3 wheel dumper?

The Mecalac TA3 wheel dumper has a travel speed of 19 km/h.

What are the undercarriage specifications of the Mecalac TA3 wheel dumper?

The Mecalac TA3 wheel dumper is equipped with standard tyres sized 295/80x15.3 10ply.

What is the turning radius of the Mecalac TA3 wheel dumper?

The Mecalac TA3 wheel dumper has an outside turning radius of 4.711 meters.

What is the material handling capacity of the Mecalac TA3 wheel dumper?

The Mecalac TA3 wheel dumper has a net load capacity of 3 tons and a dump capacity of 1.95 cubic meters.
