3.5MDX Mecalac 3.5MDX Specifications & Technical Data (2021—2026)
Technical specs - 3.5MDX Mecalac
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 2.915 t
- Standard tyres
- 295/80 R15.3 10PR
- Net load
- 3.5 t
- Dump capacity
- 1.685 m³
- Dumper type
- V
- Transport length
- 3.821 m
- Transport width
- 1.957 m
- Transport height
- 2.663 m
- Travel speed
- 20 km/h
- Loading height
- 1.419 m
- Turning radius outside
- 4.553 m
- Model series
- MDX
- Engine manuf.
- Kubota
- Engine type
- D1803
- Engine power
- 37 kW
- Displacement
- 1.8 l
- Revolutions at max torque
- 2400 rpm
- No. of cylinders
- 3
- Emission level
- V
More technical details, like: dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin and std. trough
Special equipment
- Diesel particulate filter
-
No
- Heated dump body
-
No
- All-wheel drive
-
No
- Track
-
No
- Aircondition
-
No
Download datasheets (PDF)
