Bergmann 2060R Plus Specifications & Technical Data (2016-2019)

Technical specs - 2060R Plus Bergmann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.05 t

Standard tyres: 400/70 R20 AS

Net load: 6 t

Dump capacity: 3.6 m³

Dumper type: R

Transport length: 4.489 m

Transport width: 2.018 m

Transport height: 3.107 m

Travel speed: 28 km/h

Loading height: 1.65 m

Model series: 2000

Engine manuf.: Cummins

Engine type: k.A.

Engine power: 55 kW

Revolutions at max torque: 2200 rpm

Emission level: Tier 4 f

More technical details, like: turning radius outside, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, model type, driveline, rops, fops, telematics available, engine manufacturer...

More technical details, like: turning radius outside, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, model type, driveline, rops, fops, telematics available, engine manufacturer, emission rating, rated speed, engine output, fuel, drive, tyre size - front, tyre size - rear, service type, height over rops, width, overall length, wheelbase, ground clearance, width - front tyres, width - rear tyres, width - skip, skip lip height - untipped, height over skip - untipped, payload - heaped, payload - struck, skip payload, travel speed - maximum, operating weight - unladen are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Heated dump body: No
All-wheel drive: Yes
Track: No
Aircondition: No

Download datasheets (PDF)

Bergmann 2060R Plus FAQ

When was the Bergmann 2060R Plus manufactured?

The Bergmann 2060R Plus was manufactured from 2016 to 2019.

How much does the Bergmann 2060R Plus weigh?

The Bergmann 2060R Plus weighs 4.05 tons.

What are the transport dimensions of the Bergmann 2060R Plus?

The Bergmann 2060R Plus has a transport length of 4.49 meters, a transport width of 2.02 meters, and a transport height of 3.11 meters.

What is the travel speed of the Bergmann 2060R Plus wheel dumper?

The Bergmann 2060R Plus has a travel speed of 28 km/h.

What are the undercarriage specifications of the Bergmann 2060R Plus?

The Bergmann 2060R Plus is equipped with standard tyres sized 400/70 R20 AS.

What is the material handling capacity of the Bergmann 2060R Plus wheel dumper?

The Bergmann 2060R Plus has a net load capacity of 6 tons and a dump capacity of 3.6 cubic meters.

How much is a Bergmann 2060R Plus Wheel dumper (2016u20132019) worth?

The residual value of the Bergmann 2060R Plus depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
