D 700 AP Ausa D 700 AP Specifications & Technical Data (2006—2014)

Weight: 4.2t – Standard tyres: 405/70-20 – Net load: 7t – Dump capacity: 4m³ – Dumper type: V – Transport length: 4m

D 700 AP

Years of manufacture: 2006—2014

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - D 700 AP Ausa

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.2 t

Standard tyres: 405/70-20

Net load: 7 t

Dump capacity: 4 m³

Dumper type: V

Transport length: 4 m

Transport width: 2.19 m

Transport height: 3.18 m

Travel speed: 35 km/h

Loading height: 1.73 m

Turning radius outside: 5.7 m

Model series: AP

Engine manuf.: Kubota

Engine type: V3300T

Engine power: 65 kW

More technical details, like: dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, model type, driveline, rops, engine manufacturer, engine model, rated speed, engine output, torque, fuel, drive, std tyre size front, tyre size - front, tyre size - rear, service type, height over rops, width, overall length, wheelbase, ground clearance, width - front tyres, width - rear tyres, width - skip, skip lip height - untipped, height over skip - untipped, turning radius - outside, payload - heaped, payload - struck, payload - water, skip payload, travel speed - maximum, operating weight - unladen are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Heated dump body: No
All-wheel drive: Yes
Track: No
Aircondition: No

Download datasheets (PDF)

Ausa D 700 AP FAQ

When was the Ausa D 700 AP manufactured?

The Ausa D 700 AP was manufactured from 2006 to 2014.

How much does the Ausa D 700 AP weigh?

The Ausa D 700 AP weighs 4.2 tons.

What are the transport dimensions of the Ausa D 700 AP wheel dumper?

The Ausa D 700 AP has a transport length of 4 meters, a transport width of 2.19 meters, and a transport height of 3.18 meters.

What is the travel speed of the Ausa D 700 AP wheel dumper?

The Ausa D 700 AP has a travel speed of 35 km/h.

What are the standard tyre specifications for the Ausa D 700 AP's undercarriage?

The Ausa D 700 AP is equipped with standard tyres sized 405/70-20 on its undercarriage.

What is the turning radius of the Ausa D 700 AP wheel dumper?

The Ausa D 700 AP has an outside turning radius of 5.7 meters.

What is the material handling capacity of the Ausa D 700 AP wheel dumper?

The Ausa D 700 AP wheel dumper has a net load capacity of 7 tons and a dump capacity of 4 cubic meters.
