D 601APG Ausa D 601APG Specifications & Technical Data (2019—2024)

Weight: 4.696t – Standard tyres: 405/70-20 – Net load: 6t – Dump capacity: 3.154m³ – Dumper type: D – Transport length: 5.03m

D 601APG

Years of manufacture: 2019—2024

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - D 601APG Ausa

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.696 t

Standard tyres: 405/70-20

Net load: 6 t

Dump capacity: 3.154 m³

Dumper type: D

Transport length: 5.03 m

Transport width: 2.21 m

Transport height: 3.28 m

Travel speed: 25 km/h

Loading height: 1.74 m

Turning radius outside: 5.9 m

Model series: APG

Engine manuf.: Deutz

Engine type: TD3.6 L4

Engine power: 55.4 kW

Revolutions at max torque: 2200 rpm

Max. torque: 340/1500 Nm

No. of cylinders: 4

Emission level: V

More technical details, like: dimension lxwxh, displacement, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: Yes
Heated dump body: Yes
All-wheel drive: Yes
Track: No
Aircondition: Yes

Download datasheets (PDF)

Ausa D 601APG FAQ

When was the Ausa D 601APG manufactured?

The Ausa D 601APG was manufactured from 2019 to 2024.

How much does the Ausa D 601APG weigh?

The Ausa D 601APG weighs 4.7 tons.

What are the transport dimensions of the Ausa D 601APG?

The Ausa D 601APG has a transport length of 5.03 meters, a transport width of 2.21 meters, and a transport height of 3.28 meters.

What is the travel speed of the Ausa D 601APG wheel dumper?

The Ausa D 601APG wheel dumper has a travel speed of 25 km/h.

What is the standard tyre size of the Ausa D 601APG?

The Ausa D 601APG has standard tyres sized 405/70-20.

What is the turning radius of the Ausa D 601APG wheel dumper?

The Ausa D 601APG has an outside turning radius of 5.9 meters.

What is the material handling capacity of the Ausa D 601APG wheel dumper?

The Ausa D 601APG has a net load capacity of 6 tons, a dump capacity of 3.15 cubic meters, and a loading height of 1.74 meters, featuring a three-side tipper dumper type.

How much is a Ausa D 601APG Wheel dumper (2019u20132024) worth?

The residual value of the Ausa D 601APG depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
