D 600 AP Ausa D 600 AP Specifications & Technical Data (2018—2021)

Weight: 4.2t – Standard tyres: 405/70-20 – Net load: 6t – Dump capacity: 4m³ – Dumper type: V – Transport length: 4.58m

D 600 AP

Years of manufacture: 2018—2021

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - D 600 AP Ausa

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.2 t

Standard tyres: 405/70-20

Net load: 6 t

Dump capacity: 4 m³

Dumper type: V

Transport length: 4.58 m

Transport width: 2.17 m

Transport height: 3.13 m

Travel speed: 32 km/h

Loading height: 1.635 m

Turning radius outside: 5.9 m

Model series: AP

Engine manuf.: Deutz

Engine type: TD3.6 L4

Engine power: 55.4 kW

Displacement: 3.6 l

Max. torque: 330/1600 Nm

No. of cylinders: 4

Emission level: 3B

More technical details, like: dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Heated dump body: Yes
All-wheel drive: Yes
Track: No
Aircondition: Yes

Download datasheets (PDF)

Ausa D 600 AP FAQ

When was the Ausa D 600 AP manufactured?

The Ausa D 600 AP was manufactured from 2018 to 2021.

How much does the Ausa D 600 AP wheel dumper weigh?

The Ausa D 600 AP wheel dumper weighs 4.2 tons.

What are the transport dimensions of the Ausa D 600 AP?

The Ausa D 600 AP has a transport length of 4.58 meters, a transport width of 2.17 meters, and a transport height of 3.13 meters.

What is the travel speed of the Ausa D 600 AP wheel dumper?

The Ausa D 600 AP has a travel speed of 32 km/h.

What are the undercarriage specifications of the Ausa D 600 AP?

The Ausa D 600 AP is equipped with standard tyres sized 405/70-20.

What is the turning radius of the Ausa D 600 AP wheel dumper?

The Ausa D 600 AP has an outside turning radius of 5.9 meters.

What is the material handling capacity of the Ausa D 600 AP wheel dumper?

The Ausa D 600 AP wheel dumper has a net load capacity of 6 tons and a dump capacity of 4 cubic meters.

How much is a Ausa D 600 AP Wheel dumper (2018u20132021) worth?

The residual value of the Ausa D 600 AP depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
