Technical specs - D 201 RH Ausa

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 1.6 t

Standard tyres: 10.0/75-15.3

Net load: 2 t

Dump capacity: 0.96 m³

Dumper type: V

Transport length: 4 m

Transport width: 1.59 m

Transport height: 1.45 m

Travel speed: 20 km/h

Loading height: 2.045 m

Turning radius outside: 4.19 m

Model series: RH

Engine manuf.: Kubota

Engine type: V1505

Engine power: 24 kW

More technical details, like: dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, model type, driveline, rops, fops, telematics available, engine manufacturer, engine model, rated speed, engine output, fuel, drive, tyre size - front, tyre size - rear, service type, height over rops, width, overall length, wheelbase, ground clearance, width - front tyres, width - rear tyres, width - skip, skip lip height - untipped, height over skip - untipped, turning radius - outside, payload - heaped, payload - struck, payload - water, skip payload, travel speed - maximum, operating weight - unladen are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Heated dump body: No
All-wheel drive: Yes
Track: No
Aircondition: No

Download datasheets (PDF)

Ausa D 201 RH FAQ

When was the Ausa D 201 RH manufactured?

The Ausa D 201 RH was manufactured from 2006 to 2015.

How much does the Ausa D 201 RH weigh?

The Ausa D 201 RH weighs 1.6 tons.

What are the transport dimensions of the Ausa D 201 RH wheel dumper?

The Ausa D 201 RH has a transport length of 4 meters, a transport width of 1.59 meters, and a transport height of 1.45 meters.

What is the travel speed of the Ausa D 201 RH wheel dumper?

The Ausa D 201 RH has a travel speed of 20 km/h.

What are the standard tyres of the Ausa D 201 RH?

The Ausa D 201 RH has standard tyres sized 10.0/75-15.3.

What is the outside turning radius of the Ausa D 201 RH wheel dumper?

The Ausa D 201 RH has an outside turning radius of 4.19 meters.

What is the material handling capacity of the Ausa D 201 RH wheel dumper?

The Ausa D 201 RH wheel dumper has a net load capacity of 2 tons and a dump capacity of 0.96 cubic meters.
