M335 Menzi excavator specs & dimensions (2020 - 2023)

Weight: 10.7t – Standard tyres: 600/50-22.5 – Bucket capacity: 0.4m³ – Transport length: 5.6m – Transport width: 2.35m – Transport…

Weight: 10.7t – Standard tyres: 600/50-22.5 – Bucket capacity: 0.4m³ – Transport length: 5.6m – Transport width: 2.35m – Transport height: 2.55m

Check out detailed specifications, information and technical data for Menzi M335 excavator manufactured between 2020 - 2023. Get more in-depth insight with Menzi M335 digger specifications. See information, like: Weight: 10.7t – Standard tyres: 600/50-22.5 – Bucket capacity: 0.4m³ – Transport length: 5.6m – Transport width: 2.35m – Transport height: 2.55m and more.

Technical specs - M335 Menzi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
10.7 t
Standard tyres
600/50-22.5
Bucket capacity
0.4 m³
Transport length
5.6 m
Transport width
2.35 m
Transport height
2.55 m
Max. Reach horizontal
7.77 m
Dredging depth
5 m
Tear-out force
54 kN
Bucket width
0.6 m
Engine manuf.
Deutz
Engine type
TCD3.6 LA
Engine power
100 kW
Displacement
3.6 l
Revolutions at max torque
1600 rpm
Max. torque
500/1600 Nm
No. of cylinders
4
Emission level
V

More technical details, like: model series, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, standard boom and standard bucket

Special equipment

Overload alert
Yes
Central lubrication
Yes
Aircondition
Yes
